Lexus NX AZ20 (2021-2024) heater pump assembly Wiring diagram
This page shows the only wiring diagram for the component.heater pump assembly, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater pump assembly (1 of 1)
A/C 3 FUSE
A/C MAIN FUSE
A/C- MG/V RELAY
ABS 3 FUSE
ABS- MAIN FUSE
AIR CONDITIONING AMPLIFIER ASSEMBLY
AMD 2 FUSE
BATT HTR 1 FUSE
BATT HTR 2 FUSE
BATT-S 1 FUSE
BATT-S 2 FUSE
BATTERY ECU ASSEMBLY
BATTERY STATE SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
COMPRESSOR W/ MOTOR ASSEMBLY
DEICER FUSE
DEICER RELAY
E-LATCH 1 FUSE
E-LATCH 3 FUSE
ELECTRIC VEHICLE CHARGER ASSEMBLY
FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 10)
FROM TOWING-B FUSE (DIAGRAM 1 OF 10)
GRN WIRE
H-LP CLN FUSE
H-LP CLN RELAY
HEAT PUMP ECU ASSEMBLY
HEATER PUMP ASSEMBLY
HV BATT FUSE
IGCT SCENE RELAY
IGCT-SCENE FUSE
INVERTER W/ CONVERTER ASSEMBLY
LEFT REAR SEAT
LT BLU WIRE
MG FUSE
P/SEAT (FR) FUSE
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
PTC HTR 1 FUSE
PTC HTR 1 RELAY
PTC HTR 2 FUSE
PTC HTR 2 RELAY
RED WIRE
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT POWER SEAT SWITCH
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR SEAT
S/HTR R/L FUSE
S/HTR RR FUSE
SECOND POWER SUPPLY REMOTE PARKING CIRCUIT
TOWING- ALT FUSE
TRACTION BATTERY HEATER RELAY 1
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (2 of 10) -> HEATER PUMP ASSEMBLY
