Lexus NX AZ20 (2021-2024) ev charger lid indicator assembly Wiring diagrams
This page contains all the electrical diagrams for the component. ev charger lid indicator assembly, in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ev charger lid indicator assembly wiring diagram (1 of 2)
ABSORBER CONTROL ECU
BLK WIRE
BLUETOOTH LOW ENERGY LUGGAGE DIGITAL KEY RECEIVER ASSEMBLY
BRN WIRE
CABLE EV CHARGER LOCK ASSEMBLY
CAN JUNCTION TERMINAL 2
CAN JUNCTION TERMINAL 4
DC/DC CONVERTER COOLING BLOWER ASSEMBLY
DIGITAL KEY ECU ASSEMBLY
EV CHARGER LID INDICATOR ASSEMBLY
GA (RIGHT "B" PILLAR)
GC (RIGHT SIDE OF LUGGAGE COMPT)
IGCT SCENE RELAY
IGR 3 RELAY
PPL
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT BLUETOOTH LOW ENERGY DOOR DIGITAL KEY RECEIVER ASSEMBLY
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT CUSHION HEATER (RIGHT FRONT SEAT CUSHION PAD)
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR DOOR
RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR INTERIOR ILLUMINATION LIGHT ASSEMBLY 2
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SEAT INNER BELT ASSEMBLY 1
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY (RIGHT FRONT SEAT)
THEFT WARNING SIREN ASSEMBLY
W/ ILLUMINATION ECU W/O ILLUMINATION ECU
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 8) -> EV CHARGER LID INDICATOR ASSEMBLY
ev charger lid indicator assembly wiring diagram (2 of 2)
AVS FUSE
BATTERY
BKUP LP RELAY
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
BRN WIRE
CABLE EV CHARGER LOCK ASSEMBLY
DC/DC CONVERTER ASSEMBLY
DC/DC FUSE
ECU-B 4 FUSE
ENGINE ROOM J/B 1
EV CHARGER LID INDICATOR ASSEMBLY
FAN FUSE
FAN W/ MOTOR ASSEMBLY
FOG RR RELAY
HTR FUSE
IGR 3 RELAY
INP STD 1 FUSE
INP STD 2 FUSE
LT BLU WIRE
MAIN 2 FUSE
MAIN FUSE
NCA WIRE
NOISE FILTER FUSE
P CON MAIN FUSE
P CON MTR FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY (LEFT END OF DASH)
PPL/GRN WIRE
PTC HTR 3 FUSE
PTC HTR 3 RELAY
R/B 2 FUSE
RADIO SETTING CONDENSER
RED WIRE
RR DEF RELAY
SHIFT CONTROL ACTUATOR ASSEMBLY
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STRG HTR FUSE
TO ENGINE ROOM R/B 1 (DIAGRAM 3 OF 10)
TO ENGINE ROOM R/B 2 (DIAGRAM 2 OF 10)
TO IGCT-SCENE FUSE (DIAGRAM 2 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 5 OF 10)
TOWING-B FUSE
TRANSMISSION FLOOR SHIFT ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (1 of 10) -> EV CHARGER LID INDICATOR ASSEMBLY
