Lexus NX AZ20 (2021-2024) dc/dc converter cooling blower assembly Wiring diagrams
This page contains all the electrical diagrams for the component. dc/dc converter cooling blower assembly, in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dc/dc converter cooling blower assembly (1 of 2)
ABSORBER CONTROL ECU
BLK WIRE
BLUETOOTH LOW ENERGY LUGGAGE DIGITAL KEY RECEIVER ASSEMBLY
BRN WIRE
CABLE EV CHARGER LOCK ASSEMBLY
CAN JUNCTION TERMINAL 2
CAN JUNCTION TERMINAL 4
DC/DC CONVERTER COOLING BLOWER ASSEMBLY
DIGITAL KEY ECU ASSEMBLY
EV CHARGER LID INDICATOR ASSEMBLY
GA (RIGHT "B" PILLAR)
GC (RIGHT SIDE OF LUGGAGE COMPT)
IGCT SCENE RELAY
IGR 3 RELAY
PPL
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT BLUETOOTH LOW ENERGY DOOR DIGITAL KEY RECEIVER ASSEMBLY
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT CUSHION HEATER (RIGHT FRONT SEAT CUSHION PAD)
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR DOOR
RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR INTERIOR ILLUMINATION LIGHT ASSEMBLY 2
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SEAT INNER BELT ASSEMBLY 1
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY (RIGHT FRONT SEAT)
THEFT WARNING SIREN ASSEMBLY
W/ ILLUMINATION ECU W/O ILLUMINATION ECU
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 8) -> DC/DC CONVERTER COOLING BLOWER ASSEMBLY
Wiring diagram dc/dc converter cooling blower assembly (2 of 2)
AMD
BATT-S 1 FUSE
BATT-S 2 FUSE
BHR
BHRG
BLK WIRE
BLU WIRE
BRN WIRE
CBP
CEP
DC/DC CONVERTER ASSEMBLY (UNDER RIGHT SIDE OF REAR SEAT)
DC/DC CONVERTER COOLING BLOWER ASSEMBLY
DFFS
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGCT
JUNCTION BLOCK
LEFT TRACTION BATTERY HEATER
LT GRN WIRE
LUGGAGE ROOM R/B 1
NODD
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/LT GRN WIRE
ORG/WHT WIRE
PNK WIRE
PPL/BLK WIRE
PPL/RED WIRE
PPL/VIO WIRE
RED WIRE
RIGHT TRACTION BATTERY HEATER
SHIELD
SHLD
TRACTION BATTERY HEATER RELAY 1
VIO WIRE
VLO
W/ SHIELDED
W/O SHIELDED
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 2.5l hybrid, hybrid system circuit (3 of 13) -> DC/DC CONVERTER COOLING BLOWER ASSEMBLY
