Lexus NX AZ20 (2021-2024) cooler expansion valve Wiring diagram
This page shows the only wiring diagram for the component.cooler expansion valve, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooler expansion valve (1 of 1)
A/C 2 FUSE
A/C 3 FUSE
A/C- MG/V RELAY
AIR CONDITIONING THERMISTOR ASSEMBLY 1
AIR CONDITIONING THERMISTOR ASSEMBLY 2
BLK WIRE
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
COOLER EXPANSION VALVE
DHMV
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
EVAPORATOR ELECTRIC VALVE
EVMV
GRN WIRE
GRY WIRE
HEAT PUMP ECU ASSEMBLY (LEFT SIDE OF DASH)
HIGH PRESSURE ELECTRIC VALVE
HOT AT ALL TIMES
HPL
HPMV
HPR
IGBD
LOW PRESSURE ELECTRIC VALVE
LPMV
LT GRN WIRE
ORG/ WIRE
PNK VC WIRE
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
RED/WHT WIRE
RGND
SG-4
SG-5
TCLT
TDCG
TEMPERATURE SENSOR (OUTSIDE CONDENSER EXIT SIDE)
TSCL
TSHT
TSUC
VIO WIRE
VOL (-)
WHT WIRE
WHT/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> COOLER EXPANSION VALVE
