Lexus NX AZ20 (2021-2024) blind spot monitor ind Wiring diagram
This page shows the only wiring diagram for the component.blind spot monitor ind, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blind spot monitor ind (1 of 1)
+BA 2 FUSE
1) LEFT TURN 2) LEFT LANE CHANGE 3) NEUTRAL 4) RIGHT LANE CHANGE 5) RIGHT TURN
BDSL
BLB
BLIND SPOT MONITOR IND
BRB
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR
ECU-IGR 4 FUSE
GND PPL
GRY WIRE
HOT W/ +BA 2 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
LEFT BLIND SPOT MONITOR SENSOR
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LT BLU WIRE
METER-IGR FUSE
OMIL
OMIR
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL BLGD
PPL BRGD
PPL/BLK WIRE
PPL/RED WIRE
PPL/VIO WIRE
RED WIRE
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
STEERING COLUMN)
STEERING SENSOR
STEERING WHEEL SWITCH HOUSING
TURN SIGNAL SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Blind spot monitoring circuit -> BLIND SPOT MONITOR IND
