Lexus LX J80 (1995-1997) Ground distribution circuit

A/C AMPLIFIER A/C STARTER CUT RELAY ABS ELECTRONIC CONTROL UNIT (ECU) AIRBAG SENSOR ASSEMBLY AUTO ANTENNA CONTROL SWITCH AUTO ANTENNA ECU SHIELD AUTO ANTENNA RELAY BLK WIRE BLOWER RESISTOR BLOWER SPEED CONTROL RELAY BRN WIRE CENTER DIFFERENTIAL LOCK INDICATOR SWITCH CENTER DIFFERENTIAL LOCK CONTROL MOTOR CLOCK DATA LINK CONNECTOR 1 DATA LINK CONNECTOR 3 DIFFERENTIAL LOCK ECU FRONT WIPER MOTOR EFI MAIN RELAY ENGINE CONTROL MODULE FRONT DIFFERENTIAL LOCK CONTROL MOTOR FRONT DIFFERENTIAL LOCK POSITION SWITCH GLOVE BOX LIGHT SWITCH HEATED OXYGEN SENSOR BANK 1 SENSOR 1 HEATED OXYGEN SENSOR BANK 1 SENSOR 2 J/C 8 (ABOVE RIGHT KICK PANEL) LEFT FRONT TURN SIGNAL LIGHT LEFT HEADLIGHT LOW BEAM LEFT PARKING LIGHT NCA WIRE NOISE FILTER OIL LEVEL WARNING SWITCH REAR WINDOW DEFOGGER SWITCH AUTO ANTENNA CONTROL SWITCH RIGHT DOOR KEY LOCK/ UNLOCK SWITCH RIGHT DOOR LOCK CONTROL SWITCH RIGHT FRONT DOOR UNLOCK DETECTION SWITCH RIGHT FRONT TURN SIGNAL LIGHT RIGHT HEADLIGHT LOW BEAM RIGHT PARKING LIGHT SRS SHORTING CONNECTOR STEREO COMPONENT AMPLIFIER TRANSFER NEUTRAL POSITION SWITCH VEHICLE SPEED SENSOR WATER TEMPERATURE SWITCH WHT WIRE WHT/BLK WIRE

A/C AUTOMATIC AMPLIFIER A/C SYSTEM AMPLIFIER ABS ACTUATOR ABS RELAY AIR VENT MODE CONTROL SERVO MOTOR BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH BRN WIRE CENTER DIFFERENTIAL LOCK CONTROL RELAY SEAT BELT WARNING RELAY CIGARETTE LIGHTER COMBINATION METER COOLING FAN CRUISE CONTROL ELECTRONIC CONTROL UNIT (ECU) CRUISE CONTROL SWITCH DATA LINK CONNECTOR 3 DIMMER SWITCH DOOR LOCK CONTROL RELAY LEFT DOOR KEY LOCK, UNLOCK SWITCH FLASH RELAY FROM SRS SHORTING CONNECTOR (DIAGRAM 1 OF 3) FRONT/ REAR WIPER AND WASHER SWITCH HEATER CONTROL AND A/C SWITCH HEATER SWITCH IGNITION KEY CYLINDER LIGHT IGNITION SWITCH J/C 2 (BEHIND LEFT SIDE OF DASH) J/C 7 (BEHIND GLOVE BOX) LEFT FRONT DOOR UNLOCK DETECTION SWITCH LEFT VANITY LIGHT LIGHT CONTROL SWITCH MOON ROOF CONTROL RELAY MOON ROOF CONTROL SWITCH, PERSONAL LIGHT MOON ROOF LIMIT SWITCH MOON ROOF MOTOR NCA WIRE OIL PRESSURE SENDER POWER RELAY POWER WINDOW MASTER SWITCH REAR HEATER SWITCH REMOTE CONTROLLED MIRROR SWITCH RHEOSTAT RIGHT VANITY LIGHT SEAT BELT WARNING RELAY CRUISE CONTROL ACTUATOR STATUS MONITOR THEFT DETERRENT BUZZER THEFT DETERRENT ECU VIO WIRE WHT WIRE WHT/BLK WIRE

ABS DECELERATION SENSOR BACK DOOR COURTESY SWITCH BACK DOOR LOCK DETECTION SWITCH BLK WIRE BRN WIRE DRIVER'S POWER SEAT CONTROL SWITCH FRONT PASSENGER'S POWER SEAT CONTROL SWITCH FUEL PUMP FUEL SENDER HIGH MOUNTED STOP LIGHT LEFT BUCKLE SWITCH LEFT REAR COMBINATION LIGHT LICENSE PLATE LIGHT MOBILE PHONE O/D MAIN SWITCH REAR DIFFERENTIAL LOCK CONTROL MOTOR REAR DIFFERENTIAL LOCK POSITION SWITCH REAR HEATER RELAY REAR WINDOW DEFOGGER REAR WIPER MOTOR RIGHT REAR COMBINATION LIGHT SHIFT LOCK ELECTRONIC CONTROL UNIT (ECU) TELEPHONE TRANSCEIVER/ SPEAKER RELAY WHT WIRE WHT/BLK WIRE
