Lexus LX J80 (1995-1997) transfer neutral position indicator center differential lock indicator Wiring diagram
This page shows the only wiring diagram for the component.transfer neutral position indicator center differential lock indicator, which is found in the car Lexus LX J80 (1995-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer neutral position indicator center differential lock indicator (1 of 1)
21 9 CONN D TFN
A/T INDICATOR SWITCH (LEFT SIDE OF TRANS)
BLK WIRE
BLK/ WHT WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
CENTER DIFFERENTIAL LOCK CONTROL MOTOR (TOP OF T-CASE)
CENTER DIFFERENTIAL LOCK CONTROL RELAY (ABOVE LEFT KICK PANEL)
CENTER DIFFERENTIAL LOCK INDICATOR SWITCH
DIFF FUSE
ENGINE CONTROL MODULE (RIGHT SIDE OF DASH)
FUSE BLOCK (LEFT SIDE OF DASH)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT IN ON OR START
INSTRUMENT CLUSTER
J/C 1 (LEFT SIDE OF DASH)
J/C 2 (LEFT SIDE OF DASH)
J/C 4 (LEFT DASH)
NEUTRAL DETECTION DIODE (RIGHT SIDE OF DASH)
PNK ANTI-LOCK BRAKES SYSTEM WIRE
PNK WIRE
PNK/BLK WIRE
RED WIRE
SHORT PIN (CENTER OF DASH)
SWITCH (REAR OF TRANS)
TRANSFER
TRANSFER NEUTRAL POSITION INDICATOR CENTER DIFFERENTIAL LOCK INDICATOR
TRANSFER NEUTRAL POSITION SWITCH (REAR OF TRANS)
WHT WIRE
WHT/ BLK WIRE
YEL WIRE
YEL/BLU WIRE
