Lexus LX J80 (1995-1997) tel fuse Wiring diagram
This page shows the only wiring diagram for the component.tel fuse, which is found in the car Lexus LX J80 (1995-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tel fuse (1 of 1)
ABS
BATTERY
BLK WIRE
BLU WIRE
COIL
DIMMER SWITCH, LEFT HEADLIGHT LOW BEAM, LEFT HEADLIGHT HIGH BEAM
DOME FUSE
EFI RADIO FUSE FUSE FUSE FUSE
EXTERIOR LIGHTS, ANTI-THEFT SYSTEMS
FUSIBLE LINK
FUSIBLE LINK BOX (FRONT OF BATTERY)
GENERATOR
GRN WIRE
HAZ-HORN FUSE
HEAD RELAY
IGNITION SWITCH
KEY IN IGNITION
LEFT HEAD FUSE
MAIN FUSIBLE LINK
OFF
ORG/ WIRE
RED WIRE
RIGHT HEAD FUSE
TAIL RELAY (RELAY BLOCK 1: LEFT KICK PANEL)
TEL FUSE
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
TO FUSE BLOCK (IGN FUSE) (DIAGRAM 2 OF 2)
TO FUSE BLOCK (POWER FUSIBLE LINK) (DIAGRAM 2 OF 2)
TO FUSE BLOCK (TAIL FUSE) (DIAGRAM 2 OF 2)
TO SPLICE
UNLOCK WARNING SWITCH
WARNING, ANTI-THEFT, DOOR LOCKS SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> TEL FUSE
