Lexus LX J80 (1995-1997) right door lock control switch Wiring diagram
This page shows the only wiring diagram for the component.right door lock control switch, which is found in the car Lexus LX J80 (1995-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right door lock control switch (1 of 1)
A/C AMPLIFIER
A/C STARTER CUT RELAY
ABS ELECTRONIC CONTROL UNIT (ECU)
AIRBAG SENSOR ASSEMBLY
AUTO ANTENNA CONTROL SWITCH AUTO ANTENNA ECU SHIELD AUTO ANTENNA RELAY
BLK WIRE
BLOWER RESISTOR
BLOWER SPEED CONTROL RELAY
BRN WIRE
CENTER DIFFERENTIAL LOCK INDICATOR SWITCH CENTER DIFFERENTIAL LOCK CONTROL MOTOR
CLOCK
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 3
DIFFERENTIAL LOCK ECU FRONT WIPER MOTOR
EFI MAIN RELAY
ENGINE CONTROL MODULE
FRONT DIFFERENTIAL LOCK CONTROL MOTOR
FRONT DIFFERENTIAL LOCK POSITION SWITCH
GLOVE BOX LIGHT SWITCH
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
J/C 8 (ABOVE RIGHT KICK PANEL)
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT LOW BEAM
LEFT PARKING LIGHT
NCA WIRE
NOISE FILTER
OIL LEVEL WARNING SWITCH
REAR WINDOW DEFOGGER SWITCH AUTO ANTENNA CONTROL SWITCH
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR UNLOCK DETECTION SWITCH
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT LOW BEAM
RIGHT PARKING LIGHT
SRS SHORTING CONNECTOR
STEREO COMPONENT AMPLIFIER
TRANSFER NEUTRAL POSITION SWITCH
VEHICLE SPEED SENSOR
WATER TEMPERATURE SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 3) -> RIGHT DOOR LOCK CONTROL SWITCH
