Lexus LX J80 (1995-1997) operation switch wiring diagram
This page shows the only wiring diagram for the component.operation switch, which is found in the car Lexus LX J80 (1995-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
operation switch wiring diagram (1 of 1)
FUSE BLOCK (BEHIND LEFT SIDE OF I/P)
GRN WIRE
GRY WIRE
HOT IN ACC OR ON CIG FUSE
J/C 2 (BEHIND LEFT SIDE OF DASH)
LEFT
LEFT REMOTE CONTROL MIRROR
LEFT UP RIGHT DOWN
OPERATION SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
SELECT SWITCH
UP DOWN
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirror circuit -> OPERATION SWITCH
