Lexus LX J80 (1995-1997) front washer diode Wiring diagrams
This page contains all the electrical diagrams for the component. front washer diode, in which he is found in the car Lexus LX J80 (1995-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front washer diode (1 of 2)
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH
FRONT WASHER DIODE
FRONT WIPER MOTOR (RIGHT REAR OF ENGINE COMPARTMENT)
FRONT WIPER/ WASHER SWITCH
FUSE BLOCK (LEFT SIDE OF DASH)
HIGH OFF
HOT IN ON OR START
INT LOW
J/C 7 (TOP RIGHT OF DASH)
J/C 8 (RIGHT SIDE OF DASH)
LOW INT
LT GRN WIRE
OFF
REAR WASHER DIODE
SOLID STATE
WASH
WASHER MOTOR (RIGHT FRONT OF ENGINE COMPARTMENT)
WHT/BLK WIRE
WIPER FUSE
Go to component -> Front wiper/washer circuit -> FRONT WASHER DIODE
Wiring diagram front washer diode (2 of 2)
BLK/ WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
COMBINATION SWITCH
FRONT WASHER DIODE
FUSE BLOCK (LEFT I/P)
HOT IN ON OR START
J/C 7 (TOP RIGHT OF DASH)
OFF ON INT
REAR WASHER DIODE (BEHIND LEFT I/P)
REAR WIPER CONTROL RELAY (REAR HATCH DOOR)
REAR WIPER MOTOR (LEFT SIDE OF LIFTGATE)
REAR WIPER/ WASHER SWITCH
SOLID STATE
WASHER 1 WASHER 2
WASHER 2 WASHER 1
WASHER CHANGE VALVE (LEFT REAR CORNER OF ENGINE COMPARTMENT)
WASHER MOTOR (RIGHT FRONT OF ENGINE COMPARTMENT)
WHT/BLK WIRE
WIPER FUSE
Go to component -> Rear wiper/washer circuit -> FRONT WASHER DIODE
