Lexus LX J80 (1995-1997) front passenger's power seat control switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger's power seat control switch, which is found in the car Lexus LX J80 (1995-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's power seat control switch (1 of 1)
ABS DECELERATION SENSOR
BACK DOOR COURTESY SWITCH
BACK DOOR LOCK DETECTION SWITCH
BLK WIRE
BRN WIRE
DRIVER'S POWER SEAT CONTROL SWITCH
FRONT PASSENGER'S POWER SEAT CONTROL SWITCH
FUEL PUMP
FUEL SENDER
HIGH MOUNTED STOP LIGHT
LEFT BUCKLE SWITCH
LEFT REAR COMBINATION LIGHT
LICENSE PLATE LIGHT
MOBILE PHONE
O/D MAIN SWITCH
REAR DIFFERENTIAL LOCK CONTROL MOTOR
REAR DIFFERENTIAL LOCK POSITION SWITCH
REAR HEATER RELAY
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT REAR COMBINATION LIGHT
SHIFT LOCK ELECTRONIC CONTROL UNIT (ECU)
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 3) -> FRONT PASSENGER'S POWER SEAT CONTROL SWITCH
