Wiring Diagrams Lexus LX J300 (2021-2024)

34 systems 189 wiring diagrams 1979 components

Contents — 34 systems, 189 diagrams

Active bodyworks

Active bodyworks circuit

Air conditioning

Automatic a/c circuit

Anti-lock brakes

Anti-lock brakes circuit

Anti-theft

Forced entry circuit
Immobilizer circuit

Body control modules

Body ecu circuit
Integration control and panel circuit
Semiconductor power integration ecu circuit

Computer data lines

Computer data lines circuit

Cruise control

Cruise control circuit

Defoggers

Front deicer circuit
Rear defogger & heated mirrors circuit

Electronic power steering

Electronic power steering circuit

Electronic suspension

Electronic suspension circuit, w/ adaptive variable suspension
Electronic suspension circuit, w/o adaptive variable suspension

Engine performance 3.4l turbo

Wiring diagram engine performance 3.4l turbo

Exterior lights

Backup lamps circuit
Exterior lamps circuit
Trailer tow circuit

Ground distribution

Ground distribution circuit

Headlights

Headlights circuit

Horn

Horn circuit

Instrument cluster

Instrument cluster circuit

Interior lights

Courtesy lamps circuit
Instrument illumination circuit

Memory systems

Driver"s memory seat circuit
Memory mirrors circuit, w/ door closer
Memory mirrors circuit, w/o door closer
Memory power tilt & power telescopic circuit

Navigation

Blind spot monitoring circuit
Lane departure warning circuit
Navigation circuit, 10 speaker
Navigation circuit, 25 speaker
Parking assistant circuit
Rear sonar circuit
Telematics circuit

Passive restraints

Passive restraints circuit

Power distribution

Power distribution circuit

Power door locks

Power door locks circuit

Power mirrors

Power mirrors circuit

Power seats

Front climate control seats circuit
Front heated seats circuit
Heated steering wheel circuit
Passenger power seat circuit, w/ 4 seater
Passenger power seat circuit, w/o 4 seater & stowing function
Passenger power seat circuit, w/o 4 seater w/ stowing function
Rear climate control seats circuit
Rear folding seat circuit
Rear heated seats circuit
Rear power seat circuit
Third row folding seat circuit

Power top/sunroof

Power top/sunroof circuit

Power windows

Power windows circuit

Radio

Active sound control circuit
Radio circuit, 10 speaker
Radio circuit, 25 speaker

Shift interlock

Shift interlock circuit
Steering column circuit

Starting/charging

Charging circuit
Starting circuit
Stop & start circuit

Supplemental restraints

Supplemental restraints circuit

Transmission

4wd circuit
A/t circuit

Trunk, tailgate, fuel door

Back door opener circuit

Warning systems

Seat belt warning circuit
Tire pressure monitoring circuit

Wiper/washer

Headlamp washer circuit
Wiper/washer circuit

Active bodyworks

# Active bodyworks circuit

Active bodyworks — Active bodyworks circuit — Active bodyworks circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Air conditioning

# Automatic a/c circuit

# Automatic a/c circuit (1 of 5)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (1 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Automatic a/c circuit (2 of 5)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (2 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Automatic a/c circuit (3 of 5)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (3 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Automatic a/c circuit (4 of 5)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (4 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Automatic a/c circuit (5 of 5)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (5 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

Anti-lock brakes

# Anti-lock brakes circuit

# Anti-lock brakes circuit (1 of 4)

Anti-lock brakes — Anti-lock brakes circuit — Anti-lock brakes circuit (1 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Anti-lock brakes circuit (2 of 4)

Anti-lock brakes — Anti-lock brakes circuit — Anti-lock brakes circuit (2 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Anti-lock brakes circuit (3 of 4)

Anti-lock brakes — Anti-lock brakes circuit — Anti-lock brakes circuit (3 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Anti-lock brakes circuit (4 of 4)

Anti-lock brakes — Anti-lock brakes circuit — Anti-lock brakes circuit (4 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

Anti-theft

# Forced entry circuit

# Forced entry circuit (1 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (1 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Forced entry circuit (2 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (2 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Forced entry circuit (3 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (3 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Forced entry circuit (4 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (4 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Forced entry circuit (5 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (5 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Forced entry circuit (6 of 6)

Anti-theft — Forced entry circuit — Forced entry circuit (6 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Immobilizer circuit

Anti-theft — Immobilizer circuit — Immobilizer circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Body control modules

# Body ecu circuit

# Body ecu circuit (1 of 2)

Body control modules — Body ecu circuit — Body ecu circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Body ecu circuit (2 of 2)

Body control modules — Body ecu circuit — Body ecu circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Integration control and panel circuit

Body control modules — Integration control and panel circuit — Integration control and panel circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Semiconductor power integration ecu circuit

Body control modules — Semiconductor power integration ecu circuit — Semiconductor power integration ecu circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Computer data lines

# Computer data lines circuit

# Computer data lines circuit (1 of 5)

Computer data lines — Computer data lines circuit — Computer data lines circuit (1 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Computer data lines circuit (2 of 5)

Computer data lines — Computer data lines circuit — Computer data lines circuit (2 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Computer data lines circuit (3 of 5)

Computer data lines — Computer data lines circuit — Computer data lines circuit (3 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Computer data lines circuit (4 of 5)

Computer data lines — Computer data lines circuit — Computer data lines circuit (4 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Computer data lines circuit (5 of 5)

Computer data lines — Computer data lines circuit — Computer data lines circuit (5 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

Cruise control

# Cruise control circuit

# Cruise control circuit (1 of 3)

Cruise control — Cruise control circuit — Cruise control circuit (1 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Cruise control circuit (2 of 3)

Cruise control — Cruise control circuit — Cruise control circuit (2 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Cruise control circuit (3 of 3)

Cruise control — Cruise control circuit — Cruise control circuit (3 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

Defoggers

# Front deicer circuit

Defoggers — Front deicer circuit — Front deicer circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Rear defogger & heated mirrors circuit

Defoggers — Rear defogger & heated mirrors circuit — Rear defogger & heated mirrors circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Electronic power steering

# Electronic power steering circuit

Electronic power steering — Electronic power steering circuit — Electronic power steering circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Electronic suspension

# Electronic suspension circuit, w/ adaptive variable suspension

# Electronic suspension circuit, w/ adaptive variable suspension (1 of 2)

Electronic suspension — Electronic suspension circuit, w/ adaptive variable suspension — Electronic suspension circuit, w/ adaptive variable suspension (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Electronic suspension circuit, w/ adaptive variable suspension (2 of 2)

Electronic suspension — Electronic suspension circuit, w/ adaptive variable suspension — Electronic suspension circuit, w/ adaptive variable suspension (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Electronic suspension circuit, w/o adaptive variable suspension

# Electronic suspension circuit, w/o adaptive variable suspension (1 of 2)

Electronic suspension — Electronic suspension circuit, w/o adaptive variable suspension — Electronic suspension circuit, w/o adaptive variable suspension (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Electronic suspension circuit, w/o adaptive variable suspension (2 of 2)

Electronic suspension — Electronic suspension circuit, w/o adaptive variable suspension — Electronic suspension circuit, w/o adaptive variable suspension (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Engine performance 3.4l turbo

# Wiring diagram engine performance 3.4l turbo

# Wiring diagram engine performance 3.4l turbo (1 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (1 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (2 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (2 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (3 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (3 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (4 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (4 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (5 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (5 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (6 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (6 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiring diagram engine performance 3.4l turbo (7 of 7)

Engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo — Wiring diagram engine performance 3.4l turbo (7 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

Exterior lights

# Backup lamps circuit

Exterior lights — Backup lamps circuit — Backup lamps circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Exterior lamps circuit

# Exterior lamps circuit (1 of 4)

Exterior lights — Exterior lamps circuit — Exterior lamps circuit (1 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Exterior lamps circuit (2 of 4)

Exterior lights — Exterior lamps circuit — Exterior lamps circuit (2 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Exterior lamps circuit (3 of 4)

Exterior lights — Exterior lamps circuit — Exterior lamps circuit (3 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Exterior lamps circuit (4 of 4)

Exterior lights — Exterior lamps circuit — Exterior lamps circuit (4 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Trailer tow circuit

# Trailer tow circuit (1 of 2)

Exterior lights — Trailer tow circuit — Trailer tow circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Trailer tow circuit (2 of 2)

Exterior lights — Trailer tow circuit — Trailer tow circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Ground distribution

# Ground distribution circuit

# Ground distribution circuit (1 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (1 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (2 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (2 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (3 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (3 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (4 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (4 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (5 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (5 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (6 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (6 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (7 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (7 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (8 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (8 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (9 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (9 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (10 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (10 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

# Ground distribution circuit (11 of 11)

Ground distribution — Ground distribution circuit — Ground distribution circuit (11 of 11). Lexus LX J300 (2021-2024)

Components on the diagram

Headlights

# Headlights circuit

# Headlights circuit (1 of 2)

Headlights — Headlights circuit — Headlights circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Headlights circuit (2 of 2)

Headlights — Headlights circuit — Headlights circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Horn

# Horn circuit

Horn — Horn circuit — Horn circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Instrument cluster

# Instrument cluster circuit

# Instrument cluster circuit (1 of 3)

Instrument cluster — Instrument cluster circuit — Instrument cluster circuit (1 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument cluster circuit (2 of 3)

Instrument cluster — Instrument cluster circuit — Instrument cluster circuit (2 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument cluster circuit (3 of 3)

Instrument cluster — Instrument cluster circuit — Instrument cluster circuit (3 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

Interior lights

# Courtesy lamps circuit

# Courtesy lamps circuit (1 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (1 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Courtesy lamps circuit (2 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (2 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Courtesy lamps circuit (3 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (3 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Courtesy lamps circuit (4 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (4 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Courtesy lamps circuit (5 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (5 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Courtesy lamps circuit (6 of 6)

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (6 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument illumination circuit

# Instrument illumination circuit (1 of 4)

Interior lights — Instrument illumination circuit — Instrument illumination circuit (1 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument illumination circuit (2 of 4)

Interior lights — Instrument illumination circuit — Instrument illumination circuit (2 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument illumination circuit (3 of 4)

Interior lights — Instrument illumination circuit — Instrument illumination circuit (3 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Instrument illumination circuit (4 of 4)

Interior lights — Instrument illumination circuit — Instrument illumination circuit (4 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

Memory systems

# Driver"s memory seat circuit

# Driver"s memory seat circuit (1 of 2)

Memory systems — Driver"s memory seat circuit — Driver"s memory seat circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Driver"s memory seat circuit (2 of 2)

Memory systems — Driver"s memory seat circuit — Driver"s memory seat circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Memory mirrors circuit, w/ door closer

# Memory mirrors circuit, w/ door closer (1 of 2)

Memory systems — Memory mirrors circuit, w/ door closer — Memory mirrors circuit, w/ door closer (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Memory mirrors circuit, w/ door closer (2 of 2)

Memory systems — Memory mirrors circuit, w/ door closer — Memory mirrors circuit, w/ door closer (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Memory mirrors circuit, w/o door closer

# Memory mirrors circuit, w/o door closer (1 of 2)

Memory systems — Memory mirrors circuit, w/o door closer — Memory mirrors circuit, w/o door closer (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Memory mirrors circuit, w/o door closer (2 of 2)

Memory systems — Memory mirrors circuit, w/o door closer — Memory mirrors circuit, w/o door closer (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Memory power tilt & power telescopic circuit

Memory systems — Memory power tilt & power telescopic circuit — Memory power tilt & power telescopic circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Navigation

# Lane departure warning circuit

Navigation — Lane departure warning circuit — Lane departure warning circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker

# Navigation circuit, 10 speaker (1 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (1 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (2 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (2 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (3 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (3 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (4 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (4 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (5 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (5 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (6 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (6 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 10 speaker (7 of 7)

Navigation — Navigation circuit, 10 speaker — Navigation circuit, 10 speaker (7 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker

# Navigation circuit, 25 speaker (1 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (1 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (2 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (2 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (3 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (3 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (4 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (4 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (5 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (5 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (6 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (6 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (7 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (7 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Navigation circuit, 25 speaker (8 of 8)

Navigation — Navigation circuit, 25 speaker — Navigation circuit, 25 speaker (8 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Parking assistant circuit

# Parking assistant circuit (1 of 2)

Navigation — Parking assistant circuit — Parking assistant circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Parking assistant circuit (2 of 2)

Navigation — Parking assistant circuit — Parking assistant circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear sonar circuit

Navigation — Rear sonar circuit — Rear sonar circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Telematics circuit

Navigation — Telematics circuit — Telematics circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Passive restraints

# Passive restraints circuit

Passive restraints — Passive restraints circuit — Passive restraints circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Power distribution

# Power distribution circuit

# Power distribution circuit (1 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (1 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (2 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (2 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (3 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (3 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (4 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (4 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (5 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (5 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (6 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (6 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (7 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (7 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (8 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (8 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (9 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (9 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (10 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (10 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (11 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (11 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (12 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (12 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

# Power distribution circuit (13 of 13)

Power distribution — Power distribution circuit — Power distribution circuit (13 of 13). Lexus LX J300 (2021-2024)

Components on the diagram

Power door locks

# Power door locks circuit

# Power door locks circuit (1 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (1 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Power door locks circuit (2 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (2 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Power door locks circuit (3 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (3 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Power door locks circuit (4 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (4 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Power door locks circuit (5 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (5 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

# Power door locks circuit (6 of 6)

Power door locks — Power door locks circuit — Power door locks circuit (6 of 6). Lexus LX J300 (2021-2024)

Components on the diagram

Power mirrors

# Power mirrors circuit

Power mirrors — Power mirrors circuit — Power mirrors circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Power seats

# Front climate control seats circuit

# Front climate control seats circuit (1 of 2)

Power seats — Front climate control seats circuit — Front climate control seats circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Front climate control seats circuit (2 of 2)

Power seats — Front climate control seats circuit — Front climate control seats circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Front heated seats circuit

# Front heated seats circuit (1 of 2)

Power seats — Front heated seats circuit — Front heated seats circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Front heated seats circuit (2 of 2)

Power seats — Front heated seats circuit — Front heated seats circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Heated steering wheel circuit

Power seats — Heated steering wheel circuit — Heated steering wheel circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Passenger power seat circuit, w/ 4 seater

# Passenger power seat circuit, w/ 4 seater (1 of 2)

Power seats — Passenger power seat circuit, w/ 4 seater — Passenger power seat circuit, w/ 4 seater (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Passenger power seat circuit, w/ 4 seater (2 of 2)

Power seats — Passenger power seat circuit, w/ 4 seater — Passenger power seat circuit, w/ 4 seater (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Passenger power seat circuit, w/o 4 seater & stowing function

Power seats — Passenger power seat circuit, w/o 4 seater & stowing function — Passenger power seat circuit, w/o 4 seater & stowing function. Lexus LX J300 (2021-2024)

Components on the diagram

# Passenger power seat circuit, w/o 4 seater w/ stowing function

# Passenger power seat circuit, w/o 4 seater w/ stowing function (1 of 2)

Power seats — Passenger power seat circuit, w/o 4 seater w/ stowing function — Passenger power seat circuit, w/o 4 seater w/ stowing function (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Passenger power seat circuit, w/o 4 seater w/ stowing function (2 of 2)

Power seats — Passenger power seat circuit, w/o 4 seater w/ stowing function — Passenger power seat circuit, w/o 4 seater w/ stowing function (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear climate control seats circuit

# Rear climate control seats circuit (1 of 2)

Power seats — Rear climate control seats circuit — Rear climate control seats circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear climate control seats circuit (2 of 2)

Power seats — Rear climate control seats circuit — Rear climate control seats circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear folding seat circuit

Power seats — Rear folding seat circuit — Rear folding seat circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Rear heated seats circuit

Power seats — Rear heated seats circuit — Rear heated seats circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Rear power seat circuit

# Rear power seat circuit (1 of 3)

Power seats — Rear power seat circuit — Rear power seat circuit (1 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear power seat circuit (2 of 3)

Power seats — Rear power seat circuit — Rear power seat circuit (2 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Rear power seat circuit (3 of 3)

Power seats — Rear power seat circuit — Rear power seat circuit (3 of 3). Lexus LX J300 (2021-2024)

Components on the diagram

# Third row folding seat circuit

# Third row folding seat circuit (1 of 2)

Power seats — Third row folding seat circuit — Third row folding seat circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Third row folding seat circuit (2 of 2)

Power seats — Third row folding seat circuit — Third row folding seat circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Power top/sunroof

# Power top/sunroof circuit

Power top/sunroof — Power top/sunroof circuit — Power top/sunroof circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Power windows

# Power windows circuit

# Power windows circuit (1 of 4)

Power windows — Power windows circuit — Power windows circuit (1 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Power windows circuit (2 of 4)

Power windows — Power windows circuit — Power windows circuit (2 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Power windows circuit (3 of 4)

Power windows — Power windows circuit — Power windows circuit (3 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

# Power windows circuit (4 of 4)

Power windows — Power windows circuit — Power windows circuit (4 of 4). Lexus LX J300 (2021-2024)

Components on the diagram

Radio

# Active sound control circuit

Radio — Active sound control circuit — Active sound control circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker

# Radio circuit, 10 speaker (1 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (1 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (2 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (2 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (3 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (3 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (4 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (4 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (5 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (5 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (6 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (6 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 10 speaker (7 of 7)

Radio — Radio circuit, 10 speaker — Radio circuit, 10 speaker (7 of 7). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker

# Radio circuit, 25 speaker (1 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (1 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (2 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (2 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (3 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (3 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (4 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (4 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (5 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (5 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (6 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (6 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (7 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (7 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

# Radio circuit, 25 speaker (8 of 8)

Radio — Radio circuit, 25 speaker — Radio circuit, 25 speaker (8 of 8). Lexus LX J300 (2021-2024)

Components on the diagram

Shift interlock

# Shift interlock circuit

Shift interlock — Shift interlock circuit — Shift interlock circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Steering column circuit

Shift interlock — Steering column circuit — Steering column circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Starting/charging

# Charging circuit

Starting/charging — Charging circuit — Charging circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Starting circuit

# Starting circuit (1 of 2)

Starting/charging — Starting circuit — Starting circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Starting circuit (2 of 2)

Starting/charging — Starting circuit — Starting circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Stop & start circuit

# Stop & start circuit (1 of 2)

Starting/charging — Stop & start circuit — Stop & start circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Stop & start circuit (2 of 2)

Starting/charging — Stop & start circuit — Stop & start circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Supplemental restraints

# Supplemental restraints circuit

# Supplemental restraints circuit (1 of 5)

Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (1 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Supplemental restraints circuit (2 of 5)

Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (2 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Supplemental restraints circuit (3 of 5)

Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (3 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Supplemental restraints circuit (4 of 5)

Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (4 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

# Supplemental restraints circuit (5 of 5)

Supplemental restraints — Supplemental restraints circuit — Supplemental restraints circuit (5 of 5). Lexus LX J300 (2021-2024)

Components on the diagram

Transmission

# 4wd circuit

Transmission — 4wd circuit — 4wd circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# A/t circuit

# A/t circuit (1 of 2)

Transmission — A/t circuit — A/t circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# A/t circuit (2 of 2)

Transmission — A/t circuit — A/t circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Trunk, tailgate, fuel door

# Back door opener circuit

# Back door opener circuit (1 of 2)

Trunk, tailgate, fuel door — Back door opener circuit — Back door opener circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Back door opener circuit (2 of 2)

Trunk, tailgate, fuel door — Back door opener circuit — Back door opener circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

Warning systems

# Seat belt warning circuit

# Seat belt warning circuit (1 of 2)

Warning systems — Seat belt warning circuit — Seat belt warning circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Seat belt warning circuit (2 of 2)

Warning systems — Seat belt warning circuit — Seat belt warning circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Tire pressure monitoring circuit

Warning systems — Tire pressure monitoring circuit — Tire pressure monitoring circuit. Lexus LX J300 (2021-2024)

Components on the diagram

Wiper/washer

# Headlamp washer circuit

Wiper/washer — Headlamp washer circuit — Headlamp washer circuit. Lexus LX J300 (2021-2024)

Components on the diagram

# Wiper/washer circuit

# Wiper/washer circuit (1 of 2)

Wiper/washer — Wiper/washer circuit — Wiper/washer circuit (1 of 2). Lexus LX J300 (2021-2024)

Components on the diagram

# Wiper/washer circuit (2 of 2)

Wiper/washer — Wiper/washer circuit — Wiper/washer circuit (2 of 2). Lexus LX J300 (2021-2024)

Components on the diagram
