Lexus LX J300 (2021-2024) wht/blk Wiring diagrams
This page contains all the electrical diagrams for the component. wht/blk, in which he is found in the car Lexus LX J300 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht/blk (141 of 149)
BATTERY
BLK WIRE
BRN WIRE
CANISTER PUMP MODULE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
DATA LINK CONNECTOR
DIFFERENTIAL LOCK INDICATOR SWITCH
ELECTRIC WATER PUMP ASSEMBLY
FUEL PUMP CONTROL ECU
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
INSTRUMENT PANEL REGISTER ASSEMBLY 1
INSTRUMENT PANEL REGISTER ASSEMBLY 3
INTEGRATION CONTROL ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
MAP LIGHT ASSEMBLY
MULTI- DISPLAY ASSEMBLY
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
POWER WINDOW MASTER SWITCH W/ BEZEL ASSEMBLY
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
REFRESHING SEAT SWITCH
RIGHT END OF DASH)
RIGHT FRONT POWER WINDOW SWITCH W/ BEZEL ASSEMBLY
SEAT MEMORY SWITCH
TRANSFER ASSEMBLY
TRANSMISSION CONTROL ECU ASSEMBLY
TRIP SWITCH
W/ STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 11) -> WHT/BLK WIRE
Wiring diagram wht/blk (142 of 149)
AIR BAG SENSOR W/ ECU ASSEMBLY
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION SWITCH ASSEMBLY 2
FROM GROUND IC (DIAGRAM 6 OF 11)
GLOVE BOX LIGHT ASSEMBLY
GRN WIRE
ID CODE BOX
INSTRUMENT PANEL REGISTER ASSEMBLY 2
INSTRUMENT PANEL REGISTER ASSEMBLY 4
INTEGRATION CONTROL ASSEMBLY
INTERIOR ILLUMINATION LIGHT ASSEMBLY 1
MULTIPLEX TILT, TELESCOPIC ECU
NETWORK GATEWAY ECU
PPL
PPL/BRN WIRE
PPL/RED WIRE
QQB
RAIN SENSOR
REAR MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
RED WIRE
ROOM LIGHT CONTROL RELAY
RR DEF RELAY
SHIFT LOCK CONTROL UNIT ASSEMBLY
SHIFT POSITION INDICATOR (SHIFT LOCK CONTROL UNIT ASSEMBLY)
TELEPHONE TRANSCEIVER ASSEMBLY
THEFT WARNING INDICATOR LIGHT ASSEMBLY
TOWING TAIL-S RELAY
W/ LEXUS ENFORM
W/ PARKING SUPPORT BRAKE SYSTEM
W/ STOP/ START SYSTEM
WHT/BLK WIRE
WINDSHIELD WIPER ASSEMBLY
WINDSHIELD WIPER RELAY ASSEMBLY
Go to component -> Ground distribution circuit (2 of 11) -> WHT/BLK WIRE
Wiring diagram wht/blk (143 of 149)
10 SPEAKER
25 SPEAKER
BRN WIRE
INTERIOR ILLUMINATION LIGHT ASSEMBLY 2
LEFT FRONT SEAT BELT SET
LEFT FRONT SEAT CUSHION HEATER ASSEMBLY
LEFT INTERIOR ILLUMINATION LIGHT ASSEMBLY
LEFT OCCUPANT DETECTION SENSOR
LEFT PNEUMATIC VALVE CONTROL ECU (LEFT REAR SEAT CUSHION SPRING)
LEFT POSITION CONTROL ECU ASSEMBLY
LEFT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR MULTIPLEX NETWORK DOOR ECU
LEFT REAR POWER SEAT SWITCH
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LEFT REAR SEAT BACK RELEASE MOTOR 1
LEFT REAR SEAT CUSHION HEATER ASSEMBLY 1
LEFT REAR SEAT CUSHION RELEASE MOTOR 1
LEFT REAR SEAT CUSHION SEAT CLIMATE CONTROL BLOWER ASSEMBLY 1
LEFT REAR SEAT INNER BELT ASSEMBLY 1
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
LEFT STEP LIGHT ASSEMBLY
MULTI INFORMATION DISPLAY ASSEMBLY 2
POSITION CONTROL ECU ASSEMBLY
PPL
PPL/BLK WIRE
PPL/RED WIRE
STEREO COMPONENT EQUALIZER ASSEMBLY
TO GROUND TA (DIAGRAM 8 OF 11)
VIO WIRE
W/ 4 SEATER
W/ CLIMATE CONTROL SEAT
W/ DOOR CLOSER
W/ REAR SEAT ENTERTAINMENT SYSTEM
W/O 4 SEATER
W/O CLIMATE CONTROL SEAT
W/O DOOR CLOSER
WHT/BLK WIRE
Go to component -> Ground distribution circuit (7 of 11) -> WHT/BLK WIRE
Wiring diagram wht/blk (144 of 149)
ACCELERATOR PEDAL W/ SENSOR ROD ASSEMBLY
ACT
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BB (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLU WIRE
CACH
CACL
COMPUTER DATA LINES SYSTEM
DRIVE MODE SWITCH
DSMS
ECCS
EFI 2 FUSE
EFI MAIN 2 RELAY
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
EFI- MAIN 2 FUSE
ENG- IGR 1 FUSE
ENG-IGP 1 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ETCS FUSE
FPC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 2 RELAY ENERGIZED
HOT W/ IGR 3 RELAY ENERGIZED
IGP
IGR
INSTRUMENT CLUSTER SYSTEM STARTING/CHARGING SYSTEM
INTEGRATION CONTROL, PANEL ASSEMBLY
IREL
IWPI
IWPO
LEFT PADDLE
LT GRN WIRE
MCMS
MPMP
ORG/ WIRE
PNK WIRE
PPL
PPL/PNK WIRE
PPMP
RED WIRE
RIGHT PADDLE
ROTA
ROTB
SDN
SFTD
SFTU
SHIFT SWITCH
SPIRAL CABLE SUB-ASSEMBLY
SUP
THTW
TRANSMISSION CONTROL SWITCH (SHIFT LOCK CONTROL UNIT ASSEMBLY)
TRANSMISSION SHIFT SWITCH (LEFT SIDE OF DASH)
TRANSMISSIONS SYSTEM
VCPP
VIO WIRE
VPMP
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (1 of 7) -> WHT/BLK WIRE
Wiring diagram wht/blk (145 of 149)
BLK WIRE
BLPE
BLPU
BLPV
BLPW
BLU WIRE
BRN WIRE
CAN I/F
CANISTER PUMP MODULE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ECU-IGP 3 FUSE
ECU-IGR 2 FUSE
ELECTRIC WATER PUMP ASSEMBLY
ENGINE ROOM R/B 1
FPC
FPG
FPU
FPV
FUEL PUMP CONTROL ECU (RIGHT SIDE OF CARGO AREA)
FUEL PUMP W/ FILTER ASSEMBLY
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
LED DRIVER
LEFT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 2 EXHAUST SIDE)
LEFT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 2 INTAKE SIDE)
LT GRN WIRE
METER-IGR FUSE
MGND
MTRB
NWP
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/PNK WIRE
PPL/WHT WIRE
RED WIRE
RIGHT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 1 EXHAUST SIDE)
RIGHT END OF DASH)
SGND
SPEAKER
STOP FUSE
SWP
TELLTALES
VCC
VGND
VLVB
VOUT
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (2 of 7) -> WHT/BLK WIRE
Wiring diagram wht/blk (146 of 149)
+BM
A/F 1 FUSE
A/F 2 FUSE
ACTIVE BODYWORKS SYSTEM
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 2)
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1)
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAN (+)
CFDS
COMPUTER DATA LINES SYSTEM
ECM (LEFT FRONT OF ENGINE COMPT)
EFI- B 4 FUSE
EFI-B 1 FUSE
EFI-B 2 FUSE
EFI-B 3 FUSE
EPHP
EPIM
GRN WIRE
GRY WIRE
NTP
PHPG
PIM
PNK WIRE
PPG
RED WIRE
RIGHT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 1 INTAKE SIDE)
THIM
TRANSMISSIONS SYSTEM
TURBO PRESSURE SENSOR
VACUUM SENSOR (EJECTOR)
VCPH
VCPM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (3 of 7) -> WHT/BLK WIRE
Wiring diagram wht/blk (147 of 149)
A/F FUSE
A/F RELAY
BLK WIRE
BLU WIRE
EFC+
EFI 3 FUSE
EFI 4 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN 3 RELAY
ENGINE ROOM R/B 2
FLUID COUPLING ASSEMBLY
FP-
FUEL (ENGINE ROOM SIDE) PUMP ASSEMBLY
GDFC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGN FUSE
IGT/INJ FUSE
IGT/INJ RELAY
INJ FUSE
NCFC
PNK WIRE
PORT FUEL INJECTOR ASSEMBLY 1
PORT FUEL INJECTOR ASSEMBLY 2
PORT FUEL INJECTOR ASSEMBLY 3
PORT FUEL INJECTOR ASSEMBLY 4
PORT FUEL INJECTOR ASSEMBLY 5
PORT FUEL INJECTOR ASSEMBLY 6
RED WIRE
VCFC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (5 of 7) -> WHT/BLK WIRE
Wiring diagram wht/blk (148 of 149)
BLK WIRE
BLU WIRE
BRN WIRE
DIRECT FUEL INJECTOR ASSEMBLY 1
DIRECT FUEL INJECTOR ASSEMBLY 2
DIRECT FUEL INJECTOR ASSEMBLY 3
DIRECT FUEL INJECTOR ASSEMBLY 4
DIRECT FUEL INJECTOR ASSEMBLY 5
DIRECT FUEL INJECTOR ASSEMBLY 6
E.F.I. ENGINE COOLANT TEMPERATURE SENSOR
ECF
ECM (LEFT FRONT OF ENGINE COMPT)
EPR
ETHE
EWGR
GRN WIRE
GRY WIRE
KNOCK CONTROL SENSOR (BANK 1)
KNOCK CONTROL SENSOR (BANK 2)
NCF
PNK WIRE
PTA
RED WIRE
RIGHT PCV PRESSURE SENSOR (VACUUM SENSOR)
THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY
VCF
VCPF
VCPR
VCWR
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (6 of 7) -> WHT/BLK WIRE
Wiring diagram wht/blk (149 of 149)
