Lexus LX J300 (2021-2024) telescopic shorten switch Wiring diagram
This page shows the only wiring diagram for the component.telescopic shorten switch, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram telescopic shorten switch (1 of 1)
BLK WIRE
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
ECU- DCC 1 FUSE
ECU-IGR 2 FUSE
ECUB
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
IND
LT BLU WIRE
LT GRN WIRE
MRY
MSW
MSWE
MULTIPLEX TILT, TELESCOPIC ECU
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
SEAT MEMORY SWITCH
SET-
TELESCOPIC MOTOR (STEERING COLUMN ASSEMBLY)
TELESCOPIC SHORTEN SWITCH
TELESCOPIC STRETCH SWITCH
TEM
TES
TI, TE FUSE
TILT DOWN SWITCH
TILT MOTOR (STEERING COLUMN ASSEMBLY)
TILT UP SWITCH
TILT, TELESCOPIC SWITCH
TIM
TIS
VCE
VCI
VIO WIRE
W/ DOOR CLOSER
W/O DOOR CLOSER
WHT WIRE
WHT/BLK WIRE
Go to component -> Memory power tilt & power telescopic circuit -> TELESCOPIC SHORTEN SWITCH
