Lexus LX J300 (2021-2024) speaker canh wiring diagram
This page shows the only wiring diagram for the component.speaker canh, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
speaker canh wiring diagram (1 of 1)
BBZ
BLK WIRE
BLU WIRE
BOF
BOR
BRN WIRE
CAN I/F
CBZ
CLEARANCE WARNING BUZZER 1
CLEARANCE WARNING BUZZER 2
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY
ECU-IGR 2 FUSE
EFI 1 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
LED
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT CORNER ULTRASONIC SENSOR
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR CORNER ULTRASONIC SENSOR
LT BLU WIRE
LT GRN WIRE
METER FUSE
PNK ER WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BRN WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT CORNER ULTRASONIC SENSOR
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR CORNER ULTRASONIC SENSOR
SOF
SOR
SPEAKER CANH
TAN WIRE
TELLTALES
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear sonar circuit -> SPEAKER CANH
