Lexus LX J300 (2021-2024) right rear height control sensor sub-assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right rear height control sensor sub-assembly, in which he is found in the car Lexus LX J300 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear height control sensor sub-assembly (1 of 2)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DSMS
ECU-IGR 5 FUSE
ENGINE STOP, START ECU
GRN WIRE
GRY WIRE
HEIGHT SENSOR
HOT W/ IGR 1 RELAY ENERGIZED
IGR
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT FRONT SPEED SENSOR
LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
LT GRN WIRE
MCMS
METER-IGR FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT SPEED SENSOR
RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
ROTA
ROTB
SHB
SHFL
SHFR
SHG
SHRL
SHRR
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Electronic suspension circuit, w/ adaptive variable suspension (2 of 2) -> RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
Wiring diagram right rear height control sensor sub-assembly (2 of 2)
BBC 2 FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CXPI
DRL IND
ECUB
ENG P/I-B FUSE
ENG-IGR 3 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
GRN WIRE
HEADLIGHT LEVELING ACTUATOR
HEDL
HIGH IND
HLC
HOT AT ALL TIMES
HOT W/ IGR 3 RELAY ENERGIZED
IGR
LCH
LCL
LEFT FRONT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ECU SUB-ASSEMBLY
LINL
LOW IND
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT FOG LIGHT ASSEMBLY
RIGHT HEADLIGHT ECU SUB-ASSEMBLY
RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
SBR
SGR
SHB
SHG
SHRL
SHRR
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER SYSTEM
Go to component -> Headlights circuit (2 of 2) -> RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
