Lexus LX J300 (2021-2024) right parking brake actuator assembly Wiring diagram
This page shows the only wiring diagram for the component.right parking brake actuator assembly, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right parking brake actuator assembly (1 of 1)
AIR BAG SENSOR W/ ECU ASSEMBLY
BLK WIRE
BLU WIRE
CAFH
CAFL
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ESSI
GRN WIRE
GRY WIRE
LEFT FRONT SPEED SENSOR
LT GRN WIRE
OUT
PNK WIRE
PPL/GRN WIRE
PPL/RED WIRE
RED WIRE
RIGHT FRONT SPEED SENSOR
RIGHT PARKING BRAKE ACTUATOR ASSEMBLY
RIGHT REAR SPEED SENSOR
SEMICONDUCTOR POWER INTEGRATION ECU
SPIRAL CABLE SUB-ASSEMBLY
STEERING SENSOR
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR
Go to component -> Anti-lock brakes circuit (3 of 4) -> RIGHT PARKING BRAKE ACTUATOR ASSEMBLY
