Lexus LX J300 (2021-2024) right front suspension control valve assembly Wiring diagram
This page shows the only wiring diagram for the component.right front suspension control valve assembly, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front suspension control valve assembly (1 of 1)
AHC FUSE
AHC OIL TEMPERATURE SENSOR
AHC RELAY
AVS AHC-B
BLK WIRE
BLU WIRE
BRN WIRE
BVFL
BVFR
BVRL
BVRR
CENTER CONSOLE
COMPUTER DATA LINES SYSTEM
CRFL
CRFR
CRRL
CRRR
CVL
DOWN (LO)
DSNW
ECU-IGR 3 FUSE
ENGINE ROOM R/B 1
GRN WIRE
GRY WIRE
HEIGHT CONTROL
HEIGHT CONTROL PUMP, MOTOR ASSEMBLY
HEIGHT SENSOR
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
INTEGRATION CONTROL ASSEMBLY
LEFT FRONT SPEED SENSOR
LEFT REAR HIGH CONTROL SENSOR SUB-ASSEMBLY
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM R/B 1
PNK SBL WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/VIO WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT SPEED SENSOR
RIGHT FRONT SUSPENSION CONTROL VALVE ASSEMBLY
RIGHT REAR HIGH CONTROL SENSOR SUB-ASSEMBLY
SGND
SHB
SHFL
SHFR
SHG
SHRL
SHRR
SL/BL
SLB
SLBR
SLFL
SLFR
SLRL
SLRR
SPB
SPG
STG
SUSPENSION CONTROL ECU
TOIL
UP (HI)
UPSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Electronic suspension circuit, w/o adaptive variable suspension (1 of 2) -> RIGHT FRONT SUSPENSION CONTROL VALVE ASSEMBLY
