Lexus LX J300 (2021-2024) right front fog light assembly Wiring diagram
This page shows the only wiring diagram for the component.right front fog light assembly, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front fog light assembly (1 of 1)
BBC 2 FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CXPI
DRL IND
ECUB
ENG P/I-B FUSE
ENG-IGR 3 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
GRN WIRE
HEADLIGHT LEVELING ACTUATOR
HEDL
HIGH IND
HLC
HOT AT ALL TIMES
HOT W/ IGR 3 RELAY ENERGIZED
IGR
LCH
LCL
LEFT FRONT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ECU SUB-ASSEMBLY
LINL
LOW IND
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT FOG LIGHT ASSEMBLY
RIGHT HEADLIGHT ECU SUB-ASSEMBLY
RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
SBR
SGR
SHB
SHG
SHRL
SHRR
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER SYSTEM
Go to component -> Headlights circuit (2 of 2) -> RIGHT FRONT FOG LIGHT ASSEMBLY
