Lexus LX J300 (2021-2024) right curtain shield air bag assembly Wiring diagram
This page shows the only wiring diagram for the component.right curtain shield air bag assembly, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right curtain shield air bag assembly (1 of 1)
A/BAG-IGR FUSE
ACL
AIR BAG SENSOR W/ ECU ASSEMBLY
BLK WIRE
BRN WIRE
CAFH
CAFL
COMPUTER DATA LINES SYSTEM
DK+
DRIVER SIDE SQUIB CIRCUIT (HORN BUTTON ASSEMBLY)
FRONT SIDE
GNDR
GRY WIRE
GSW
IC ID
ICR+
IGR
INSTRUMENT PANEL PASSENGER AIR BAG W/0 DOOR ASSEMBLY
LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 1 KNEE AIR BAG
LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 2 KNEE AIR BAG
PK-
POWER DISTRIBUTION BOX ASSEMBLY
PR-
PRETENSIONER
PRR-
RCR
REAR SIDE
RED WIRE
RELAY ENERGIZED
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY
RIGHT END OF DASH)
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT SEAT AIR BAG ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
RIGHT REAR SEAT AIR BAG ASSEMBLY
RIGHT REAR SEAT CUSHION AIR BAG ASSEMBLY
SELECTABLE FORCE LIMITER
SFR-
SL-
SPIRAL CABLE SUB-ASSEMBLY
SR-
SRR+
W/ 4 SEATER
W/ POWER SEAT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 5) -> RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY
