Lexus LX J300 (2021-2024) rear seat lap type belt assembly center Wiring diagram
This page shows the only wiring diagram for the component.rear seat lap type belt assembly center, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear seat lap type belt assembly center (1 of 1)
ABSORBER CONTROL ECU
BLK WIRE
BLOWER MOTOR CONTROL
BRN WIRE
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
CONSOLE BOX LIGHT SUB- ASSEMBLY
CONTROL SWITCH ASSEMBLY
COOLER CONTROL SWITCH ASSEMBLY
COOLING BOX AMPLIFIER (COOLING BOX ASSEMBLY)
FOLD SEAT CONTROL ECU
FROM GROUND QA (DIAGRAM 10 OF 11)
FROM GROUND QA (DIAGRAM 9 OF 11)
GRN WIRE
JUNCTION TERMINAL 2
JUNCTION TERMINAL 3
JUNCTION TERMINAL 4
LEFT REAR SEAT INNER BELT ASSEMBLY 2
OCCUPANT DETECTION SENSOR
POWER OUTLET SOCKET ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BRN WIRE
PPL/WHT WIRE
REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY
REAR MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
REAR SEAT INNER BELT SUB-ASSEMBLY 2
REAR SEAT LAP TYPE BELT ASSEMBLY CENTER
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT OCCUPANT DETECTION SENSOR
RIGHT PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT CUSHION SPRING)
RIGHT POSITION CONTROL ECU ASSEMBLY
RIGHT REAR POWER SEAT SWITCH
RIGHT REAR SEAT BACK RELEASE MOTOR 1
RIGHT REAR SEAT CUSHION AIR BAG ASSEMBLY
RIGHT REAR SEAT CUSHION HEATER ASSEMBLY
RIGHT REAR SEAT CUSHION HEATER ASSEMBLY 1
RIGHT REAR SEAT CUSHION SEAT CLIMATE CONTROL BLOWER ASSEMBLY 1
RIGHT STEP LIGHT ASSEMBLY
SUSPENSION CONTROL ECU
VIO WIRE
W/ 4 SEATER
W/ CLIMATE CONTROL SEAT
W/0 4 SEATER
W/0 CLIMATE CONTROL SEAT
W/O 4 SEATER
WHT WIRE
WHT/BLK (OR PPL/BLK) WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 11) -> REAR SEAT LAP TYPE BELT ASSEMBLY CENTER
