Lexus LX J300 (2021-2024) rear blower motor w/ fan sub-assembly Wiring diagrams
This page contains all the electrical diagrams for the component. rear blower motor w/ fan sub-assembly, in which he is found in the car Lexus LX J300 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear blower motor w/ fan sub-assembly (1 of 2)
BLK WIRE
BLOWER MOTOR CONTROL
BLU WIRE
BRN WIRE
CDS FAN FUSE
CDS FAN RELAY
CONTROL SWITCH ASSEMBLY
COOLING BOX AMPLIFIER (COOLING BOX ASSEMBLY)
ECU- IGP 2 FUSE
ECU-IGP 3 FUSE
ENGINE ROOM R/B 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
PTC 1 RELAY
PTC 2 RELAY
PTC 3 RELAY
QUICK HEATER ASSEMBLY (TOP OF CENTER CONSOLE)
REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY
RED WIRE
RIGHT END OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Automatic a/c circuit (2 of 5) -> REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY
Wiring diagram rear blower motor w/ fan sub-assembly (2 of 2)
ABSORBER CONTROL ECU
BLK WIRE
BLOWER MOTOR CONTROL
BRN WIRE
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
CONSOLE BOX LIGHT SUB- ASSEMBLY
CONTROL SWITCH ASSEMBLY
COOLER CONTROL SWITCH ASSEMBLY
COOLING BOX AMPLIFIER (COOLING BOX ASSEMBLY)
FOLD SEAT CONTROL ECU
FROM GROUND QA (DIAGRAM 10 OF 11)
FROM GROUND QA (DIAGRAM 9 OF 11)
GRN WIRE
JUNCTION TERMINAL 2
JUNCTION TERMINAL 3
JUNCTION TERMINAL 4
LEFT REAR SEAT INNER BELT ASSEMBLY 2
OCCUPANT DETECTION SENSOR
POWER OUTLET SOCKET ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BRN WIRE
PPL/WHT WIRE
REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY
REAR MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
REAR SEAT INNER BELT SUB-ASSEMBLY 2
REAR SEAT LAP TYPE BELT ASSEMBLY CENTER
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT OCCUPANT DETECTION SENSOR
RIGHT PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT CUSHION SPRING)
RIGHT POSITION CONTROL ECU ASSEMBLY
RIGHT REAR POWER SEAT SWITCH
RIGHT REAR SEAT BACK RELEASE MOTOR 1
RIGHT REAR SEAT CUSHION AIR BAG ASSEMBLY
RIGHT REAR SEAT CUSHION HEATER ASSEMBLY
RIGHT REAR SEAT CUSHION HEATER ASSEMBLY 1
RIGHT REAR SEAT CUSHION SEAT CLIMATE CONTROL BLOWER ASSEMBLY 1
RIGHT STEP LIGHT ASSEMBLY
SUSPENSION CONTROL ECU
VIO WIRE
W/ 4 SEATER
W/ CLIMATE CONTROL SEAT
W/0 4 SEATER
W/0 CLIMATE CONTROL SEAT
W/O 4 SEATER
WHT WIRE
WHT/BLK (OR PPL/BLK) WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 11) -> REAR BLOWER MOTOR W/ FAN SUB-ASSEMBLY
