Lexus LX J300 (2021-2024) panel relay Wiring diagram
This page shows the only wiring diagram for the component.panel relay, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel relay (1 of 1)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONSOLE BOX LIGHT SUB- ASSEMBLY
CONTROL SWITCH ASSEMBLY
COOLER CONTROL SWITCH ASSEMBLY
CXPI
ECU-DCC 2 FUSE
ECU-IGR 2 FUSE
ECU-IGR 3 FUSE
ENGINE ROOM J/B 1
FOLD SEAT SWITCH ASSEMBLY 1
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
IGR
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
MAIN BODY ECU
METER-IGR FUSE
PANEL RELAY
PDB ALT 1 FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
REAR MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT LICENSE PLATE LIGHT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR POWER SEAT SWITCH
TAIL
TAIL RELAY
VIO WIRE
W/ POWER SEAT
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (1 of 4) -> PANEL RELAY
