Lexus LX J300 (2021-2024) left front seat outer belt assembly pretensioner Wiring diagram
This page shows the only wiring diagram for the component.left front seat outer belt assembly pretensioner, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front seat outer belt assembly pretensioner (1 of 1)
BLK WIRE
BLU WIRE
CAN I/F
CANN
CANP
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER DISPLAY
ENGINE ROOM R/B 1
GRN WIRE
GSW
HOT AT ALL TIMES
LED DRIVER
LEFT FRONT AIR BAG SENSOR
LEFT FRONT SEAT AIR BAG ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY PRETENSIONER
LEFT REAR SEAT AIR BAG ASSEMBLY
LT BLU WIRE
METER FUSE
RED WIRE
SFL-
SL-
TELEPHONE TRANSCEIVER ASSEMBLY
TELLTALES
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (4 of 5) -> LEFT FRONT SEAT OUTER BELT ASSEMBLY PRETENSIONER
