Lexus LX J300 (2021-2024) grille shutt fuse Wiring diagram
This page shows the only wiring diagram for the component.grille shutt fuse, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram grille shutt fuse (1 of 1)
BBC 2 FUSE
BIN 2
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
GRILLE SHUTT FUSE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IG 12
LED DRIVER
METER-IGR FUSE
MOTOR
POWER DISTRIBUTION BOX ASSEMBLY
RADIATOR SHUTTER ASSEMBLY
RED WIRE
RIGHT END OF DASH)
TELLTALES
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Active bodyworks circuit -> GRILLE SHUTT FUSE
