Lexus LX J300 (2021-2024) engine room r/b no 1 Wiring diagram
This page shows the only wiring diagram for the component.engine room r/b no 1, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine room r/b no 1 (1 of 1)
BKUP LP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECU-IGP 3 FUSE
ENG-IGR 2 FUSE
ENGINE CONTROLS SYSTEM
ENGINE ROOM R/B NO 1
ENGINE STOP, START ECU
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
HOT W/ IGR 3 RELAY ENERGIZED
IGB
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/PNK WIRE
RED WIRE
RIGHT END OF DASH)
SGND
SHIFT POSITION INDICATOR (SHIFT LOCK CONTROL UNIT ASSEMBLY)
STOP FUSE
TRANSMISSION CONTROL ECU ASSEMBLY
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
Go to component -> Cruise control circuit (2 of 3) -> ENGINE ROOM R/B NO 1
