Lexus LX J300 (2021-2024) center rear seat lap type belt assembly Wiring diagram
This page shows the only wiring diagram for the component.center rear seat lap type belt assembly, which is found in the car Lexus LX J300 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center rear seat lap type belt assembly (1 of 1)
AIR BAG SENSOR W/ ECU ASSEMBLY
BLK WIRE
BLU WIRE
BUCKLE SWITCH
CAN (+)
CENTER REAR SEAT LAP TYPE BELT ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-DCC 2 FUSE
GNDL
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
LBR-
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT SEAT BELT SET
LEFT REAR SEAT INNER BELT ASSEMBLY 1
LEFT REAR SEAT INNER BELT ASSEMBLY 2
LHB-
MAIN BODY ECU
METER-IGR FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/RED WIRE
PPL/WHT WIRE
REAR SEAT INNER BELT SUB-ASSEMBLY 2
RED WIRE
RIGHT END OF DASH)
SA (FRONT OF LEFT REAR DOOR)
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Seat belt warning circuit (1 of 2) -> CENTER REAR SEAT LAP TYPE BELT ASSEMBLY
