Lexus LX J300 (2021-2024) bbc 2 fuse Wiring diagrams
This page contains all the electrical diagrams for the component. bbc 2 fuse, in which he is found in the car Lexus LX J300 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bbc 2 fuse (1 of 8)
BBC 2 FUSE
BIN 2
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
GRILLE SHUTT FUSE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IG 12
LED DRIVER
METER-IGR FUSE
MOTOR
POWER DISTRIBUTION BOX ASSEMBLY
RADIATOR SHUTTER ASSEMBLY
RED WIRE
RIGHT END OF DASH)
TELLTALES
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Active bodyworks circuit -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (2 of 8)
ALT FUSE
ALT-CDS FUSE
BATT-S 1 FUSE
BATT-S 2 FUSE
BATTERY
BATTERY STATE SENSOR ASSEMBLY
BBC 2 FUSE
BIN 2
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY
ENGINE ROOM J/B 1
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
FUSIBLE LINK BLOCK ASSEMBLY
GENERATOR W/ REGULATOR ASSEMBLY
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IG 12
LED DRIVER
METER-IGR FUSE
NCA WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RBAT
RED WIRE
RIGHT END OF DASH)
TELLTALES
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Charging circuit -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (3 of 8)
BBC 2 FUSE
BIN 2
BLK WIRE
BLU WIRE
CAN I/F CANL
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
EPS-1 FUSE
EPS-2 FUSE
EPS-IGR FUSE
GNDB
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
LED DRIVER
METER-IGR FUSE
PIGB
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY)
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
STEERING TORQUE SENSOR (RACK, PINION POWER STEERING GEAR ASSEMBLY)
TELLTALES
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT/BLK WIRE
Go to component -> Electronic power steering circuit -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (4 of 8)
BBC 2 FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CXPI
DRL IND
ECUB
ENG P/I-B FUSE
ENG-IGR 3 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
GRN WIRE
HEADLIGHT LEVELING ACTUATOR
HEDL
HIGH IND
HLC
HOT AT ALL TIMES
HOT W/ IGR 3 RELAY ENERGIZED
IGR
LCH
LCL
LEFT FRONT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ECU SUB-ASSEMBLY
LINL
LOW IND
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT FOG LIGHT ASSEMBLY
RIGHT HEADLIGHT ECU SUB-ASSEMBLY
RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
SBR
SGR
SHB
SHG
SHRL
SHRR
WHT WIRE
WHT/BLK WIRE
WIPER/WASHER SYSTEM
Go to component -> Headlights circuit (2 of 2) -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (5 of 8)
AUTO TAIL OFF HEAD
BBC 2 FUSE
BLK WIRE
BLU WIRE
CAN I/F
CENTER CONSOLE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 2
COMPUTER DATA LINES SYSTEM
DISPLAY
ENGINE ROOM R/B 2
GRN WIRE
HEAD
HOT AT ALL TIMES
INTEGRATION CONTROL ASSEMBLY
L OFF
LED DRIVER
LIGHT CONTROL SWITCH
OFF
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/ORG WIRE
PPL/RED WIRE
RED WIRE
SHIFT POSITION INDICATOR (SHIFT LOCK CONTROL UNIT ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY
STEERING WHEEL SWITCH HOUSING
TAIL AUTO HEAD
TELLTALES
TURN SIGNAL SWITCH
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (2 of 4) -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (6 of 8)
BBC 2 FUSE
BIN 2
BLK WIRE
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
ECU-ACC FUSE
ECU-IGR 1 FUSE
ECU-IGR 2 FUSE
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM CRUISE CONTROL SYSTEM
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
HSW
IA (LEFT END OF DASH)
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEMS
INTEGRATION CONTROL, PANEL ASSEMBLY
NAVIGATION, SOUND SYSTEMS
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
STARTING/CHARGING SYSTEM
TRANSMISSIONS SYSTEM
VIO WIRE
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Integration control and panel circuit -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (7 of 8)
4 WHEEL DRIVE CONTROL ECU
A/F FUSE
A/F RELAY
ABS 1 FUSE
ABS 2 FUSE
ABS MAIN 2 FUSE
ABS MTR 1 FUSE
ABS- MAIN 1 FUSE
BBC 1 FUSE
BBC 2 FUSE
BLK WIRE
BLU WIRE
BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
EDU FUSE
EDU RELAY
EFI 2 FUSE
EFI MAIN 2 RELAY
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
EFI- MAIN 2 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN 3 RELAY
ENGINE ROOM J/B 2
ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT)
ENGINE STOP, START ECU
ETCS FUSE
FROM ENGINE ROOM J/B 1 (DIAGRAM 1 OF 13)
FROM IGP 2 RELAY (DIAGRAM 5 OF 13)
IGT/INJ FUSE
IGT/INJ RELAY
LT GRN WIRE
PNK WIRE
RED WIRE
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
ST 1 FUSE
ST 1 RELAY
ST 2 FUSE
ST 2 RELAY
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (6 of 13) -> BBC 2 FUSE
Wiring diagram bbc 2 fuse (8 of 8)
10 SPEAKER
25 SPEAKER
ANTI-LOCK BRAKES SYSTEM
BBC 1 FUSE
BBC 2 FUSE
BI (RIGHT END OF DASH)
BIN
BJ (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
CLL
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DGND
ECAN
ECO RUN CANCEL SWITCH
ECO-RUN VEHICLE CONVERTER ASSEMBLY (RIGHT FRONT CORNER OF ENGINE COMPT)
ECU-ACC FUSE
ECU-IGP 3 FUSE
ECU-IGR 5 FUSE
EFI 1 FUSE
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
IGP
IGR
NOPM
ORG/ WIRE
PA-BBC FUSE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
STARTING CIRCUIT
STEREO COMPONENT AMPLIFIER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Stop & start circuit (1 of 2) -> BBC 2 FUSE
