Lexus LX J300 (2021-2024) battery state sensor assembly Wiring diagrams
This page contains all the electrical diagrams for the component. battery state sensor assembly, in which he is found in the car Lexus LX J300 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram battery state sensor assembly (1 of 2)
ALT FUSE
ALT-CDS FUSE
BATT-S 1 FUSE
BATT-S 2 FUSE
BATTERY
BATTERY STATE SENSOR ASSEMBLY
BBC 2 FUSE
BIN 2
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY
ENGINE ROOM J/B 1
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
FUSIBLE LINK BLOCK ASSEMBLY
GENERATOR W/ REGULATOR ASSEMBLY
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IG 12
LED DRIVER
METER-IGR FUSE
NCA WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RBAT
RED WIRE
RIGHT END OF DASH)
TELLTALES
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Charging circuit -> BATTERY STATE SENSOR ASSEMBLY
Wiring diagram battery state sensor assembly (2 of 2)
10 SPEAKER 25 SPEAKER
AMP 1 FUSE
AMP 2 FUSE
BATT-S 1 FUSE
BATT-S 2 FUSE
BATTERY STATE SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
CDS FAN RELAY
DCM FUSE
ECO RUN VEHICLE CONVERTER ASSEMBLY
ECU- IGP 2 FUSE
ECU-IGP 3 FUSE
ENG P/I-B FUSE
FROM EPS 1 FUSE (DIAGRAM 1 OF 13)
GRN WIRE
HORN FUSE
HORN RELAY
IGP 1 RELAY
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY
MULTI INFORMATION DISPLAY ASSEMBLY 1
MULTI INFORMATION DISPLAY ASSEMBLY 2
PA-BBC FUSE
PNK WIRE
PPL
PPL/PNK WIRE
RED WIRE
RSE DISP FUSE
S-HORN FUSE
S/HTR F/L FUSE
SEMICONDUCTOR POWER INTEGRATION ECU
SHIFT LOCK CONTROL UNIT ASSEMBLY
STEREO COMPONENT AMPLIFIER ASSEMBLY
TELEPHONE TRANSCEIVER ASSEMBLY
THEFT WARNING SIREN ASSEMBLY
TO ALT FUSE (DIAGRAM 3 OF 13)
TO LUGGAGE ROOM R/B 1 (DIAGRAM 5 OF 13)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 10 OF 13)
TO S/HTR FR FUSE (DIAGRAM 3 OF 13)
W/ 4 SEATER
W/ REAR SEAT ENTERTAINMENT SYSTEM
W/ STOP/ START SYSTEM
W/O 4 SEATER
W/O STOP/ START SYSTEM
WHT WIRE
Go to component -> Power distribution circuit (2 of 13) -> BATTERY STATE SENSOR ASSEMBLY
