Rear power seat circuit for Lexus LX J200 facelift (2012-2015)
Rear power seat circuit
BLU WIRE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
LEFT REAR POWER SEAT SLIDE POSITION MOTOR (UNDER LEFT REAR SEAT)
LEFT REAR POWER SEAT SWITCH 1
RED WIRE
RIGHT REAR POWER SEAT SLIDE POSITION MOTOR (UNDER RIGHT REAR SEAT)
RIGHT REAR POWER SEAT SWITCH 1
RR P/SEAT FUSE
WHT/BLK WIRE
