Lexus LX J200 facelift (2012-2015) vci tis tim+ Wiring diagram
This page shows the only wiring diagram for the component.vci tis tim+, which is found in the car Lexus LX J200 facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vci tis tim+ (1 of 1)
1 21 10 6 7 8 9 CANH CANL MSWE
15 16 CANN CANP
BLK WIRE
BLU WIRE
BRN WIRE
CANN
COMPUTER DATA LINES SYSTEM
DCTY
ECU- IG 1 FUSE
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE FUSE OF ENGINE COMPT)
HOT IN ON OR START
ILL ILL
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT FRONT DOOR COURTESY SWITCH (LEFT "B" PILLAR)
LEFT FRONT SEAT MEMORY SWITCH
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
MRY
OUTER MIRROR CONTROL ECU (DRIVER'S DOOR)
PNK WIRE
RED WIRE
RED/BLU WIRE
SET-
TELESCOPIC SHRINK
TELESCOPIC STRETCH
TEM+ TELESCOPIC MOTOR MULTIPLEX TILT, TELESCOPIC ECU (ON STEERING COLUMN)
TES
TI, TE FUSE
TILT DOWN
TILT SENSOR TILT MOTOR POWER TILT MOTOR (ON STEERING COLUMN)
TILT UP
TILT, TELESCOPIC SWITCH
TIM- GND
VCE TELESCOPIC SENSOR TEM-
VCI TIS TIM+
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Memory power tilt & power telescopic circuit -> VCI TIS TIM+
