Lexus LX J200 facelift (2012-2015) toil stg spg pacc shfl Wiring diagram
This page shows the only wiring diagram for the component.toil stg spg pacc shfl, which is found in the car Lexus LX J200 facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram toil stg spg pacc shfl (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 GND
1 2 3 4 5 6 BAT RAL- RAL+ RBR- RAR+ GND
7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 RBL- RBL+
ABSORBER CONTROL SWITCH EASY ACCESS MODE
AHC-B 2 FUSE
AHC-B FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
COMPUTER DATA LINES SYSTEM
ECU-IG 4 FUSE
ERL
ERR
FUEL TEMPERATURE SENSOR (AT FUEL TANK)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IG 4 RELAY ENERGIZED
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT "C" PILLAR)
LEFT FRONT HEIGHT CONTROL SENSOR (LEFT INNER FENDER PANEL)
LEFT REAR SHOCK ABSORBER ASSEMBLY (UNDER LEFT SIDE OF VEHICLE)
LMSW TD
LT GRN WIRE
PACC
PRESSURE ACCUMULATOR SENSOR (UNDER RIGHT REAR OF VEHICLE)
RAL+
RAR+
RBL-
RBR+ RAR-
RBR-
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT HEIGHT CONTROL SENSOR (RIGHT FRONT INNER FENDER PANEL)
RIGHT REAR SHOCK ABSORBER ASSEMBLY (UNDER RIGHT SIDE OF VEHICLE)
SBL
SGFR
SHB
SHFL
SHFR
SHG
SPB
SUSPENSION CONTROL ECU (LEFT QUARTERPANEL)
TOIL
TOIL STG SPG PACC SHFL
UPSW DNSW SGFL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Electronic suspension circuit (1 of 3) -> TOIL STG SPG PACC SHFL
