Lexus LX J200 facelift (2012-2015) speed selector switch, crawl on/off switch, transfer position switch Wiring diagram
This page shows the only wiring diagram for the component.speed selector switch, crawl on/off switch, transfer position switch, which is found in the car Lexus LX J200 facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed selector switch, crawl on/off switch, transfer position switch (1 of 1)
+BI
+BO
1 2 3 9 10 IG ESS BATT
11 10 CANL CANH PNK WIRE
ABS IND.
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR
BRAKE IND
BRK-LP RELAY
BRN WIRE
BRN/YEL WIRE
BUZZER
CANL CANH
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CRAWL IND
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM
FOUR WHEEL DRIVE CONTROL ECU (RIGHT END OF DASH)
FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HSW
INTEGRATION CONTROL, PANEL ASSEMBLY
JUNCTION
JUNCTION CONNECTOR
JUNCTION CONNECTORS
LBL
LEFT COWL SIDE J/B (LEFT END OF DASH)
MASTER IND
MET R/B FUSE (LEFT SIDE OF ENGINE COMPT)
MULTI-DISPLAY
OTA
OUT
PNK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED
SLIP IND
SPEED SELECTOR SWITCH, CRAWL ON/OFF SWITCH, TRANSFER POSITION SWITCH
STEERING CONTROL ECU (LEFT END OF DASH)
STEERING SENSOR (IN STEERING COLUMN)
STOP LIGHT CONTROL RELAY (LEFT SIDE OF DASH)
STOP LIGHT SWITCH (LEFT SIDE OF DASH)
TRAC OFF IND
VIO WIRE
VSC OFF IND
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> SPEED SELECTOR SWITCH, CRAWL ON/OFF SWITCH, TRANSFER POSITION SWITCH
