Lexus LX J200 facelift (2012-2015) ptc htr 1 noise filter relay filter wiring diagram
This page shows the only wiring diagram for the component.ptc htr 1 noise filter relay filter, which is found in the car Lexus LX J200 facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ptc htr 1 noise filter relay filter wiring diagram (1 of 1)
A/F RELAY
AHC RELAY
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RECEIVER ASSEMBLY)
CONDENSER BLOWER MOTOR ASSEMBLY
ECM ENGINE (ENGINE HOOD CONTROL COURTESY SWITCH MODULE)
ENGINE OIL EFI LEVEL RELAY SENSOR
EXHAUST GAS SENSOR
FROM JUNCTION
FRONT BLOWER W/ FAN MOTOR SUB- ASSEMBLY
FRONT WIPER DEICER (WINDSHIELD GLASS)
HEADLIGHT CLEANER CONTROL RELAY, MOTOR
JUNCTION
LEFT FOG RIGHT FOG LIGHT LIGHT ASSEMBLY ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
LEFT REAR SPEED SENSOR SHIELD
LEFT RIGHT FRONT FRONT SPEED SPEED SENSOR SENSOR SHIELD SHIELD
NCA WIRE
NOISE EFI RELAY 2
NOISE FILTER
PTC HTR 1 NOISE FILTER RELAY FILTER
PTC HTR 2 RELAY
PTC HTR 3 RELAY
RELAY
RIGHT HEADLIGHT ASSEMBLY
RIGHT REAR SPEED SENSOR SHIELD
SHORT CONNECTOR
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY
ST CUT RELAY
STOP LIGHT CONTROL RELAY ASSEMBLY
SUB ST BATT RELAY RELAY
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 6) -> PTC HTR 1 NOISE FILTER RELAY FILTER
