Lexus LX J200 facelift (2012-2015) ecu change- over switch main switch assembly Wiring diagram
This page shows the only wiring diagram for the component.ecu change- over switch main switch assembly, which is found in the car Lexus LX J200 facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecu change- over switch main switch assembly (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 B(+)
BCB+
BCV-
BGND
BLK WIRE
BLSW
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CB+ CV+
CLEARANCE WARNING BUZZER 1 (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CSSW
ECU CHANGE- OVER SWITCH MAIN SWITCH ASSEMBLY
ECU- IG 1 FUSE
FRONT TELEVISION CAMERA (CENTER FRONT OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
GVIF
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) RAD 1 FUSE
HOT W/ ACC RELAY ENERGIZED
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT ULTRASONIC SENSOR 1 (LEFT CORNER OF FRONT BUMPER)
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
MPOS EF BBZ IG
OUTER MIRROR SWITCH ASSEMBLY
PARKING ASSIST ECU (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RELAY ENERGIZED
RET
RIGHT ULTRASONIC SENSOR 1 (RIGHT CORNER OF FRONT BUMPER)
SCB+ SGND SCV- BGND BCV- CGND CV- CANL CANH SHIELD
SCV+ BCB+ BCV+
SHIELD
SHIELD 11 12 13 14
SHIELD 3 4 5 6 7 8 9
SHIELD SHIELD
SONAR SWITCH
TX- TX+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> ECU CHANGE- OVER SWITCH MAIN SWITCH ASSEMBLY
