Lexus LX J200 facelift (2012-2015) cruise ind center differential lock ind Wiring diagram

1 R/O 2 CHG- 23 OIL 28 WLVL 24 FLDS 25 MSSL 26 ET 27 RSET 30 IG+ 31 TC 32 ILL+ 33 TR 35 CANL 36 CANH 37 MPX+ 38 MPX- 39 WRNP 6 +S 5 SI ABS IND TIRE PRESSURE IND ACCESS MODE IND AFS OFF IND ANTI-THEFT SYSTEM AT P IND BEAM IND BLINK BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BRAKE IND BRN WIRE BUZZER CHARGE CLEARANCE SONAR COMBINATION METER COMPUTER DATA LINES SYSTEM CRAWL IND CRUISE IND CENTER DIFFERENTIAL LOCK IND DIM ONE STEP DOOR IND DRIVER SEAT BELT IND ECT POWER IND EEPROM ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FRONT FOG IND FUEL GAUGE FUEL LEVEL IND FUSE GRN WIRE HEAD IND HOT AT ALL TIMES HOT W/ IG B+ ILL- 20 EP ILLUMINATION IND IND INTERIOR LIGHTS SYSTEM ENGINE CONTROLS SYSTEM LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT TURN IND LIGHT CONTROL RHEOSTAT IND LT GRN WIRE LVL MALFUNCTION INDICATOR LAMP MASTER MET FUSE MULTI-DISPLAY MULTI-MEDIA MODULE RECEIVER ASSEMBLY NAVIGATION SYSTEM ODO/TRIP OIL OIL PRESSURE GAUGE ONE STEP DIM PCS IND PNK WIRE POWER SUPPLY CIRCUIT RED WIRE RED/BLU WIRE RHEOSTAT RIGHT TURN IND RSCA OFF IND SEATS SYSTEM SECURITY IND SET IND SLIP IND SPDP SPEEDOMETER SRS IND STARTING/ CHARGING SYSTEM STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) SUPPLEMENTAL RESTRAINTS SYSTEM TACHOMETER TAIL CANCEL TAIL IND TEMP GAUGE TRAC OFF IND USA VIO VIO WIRE VIO WIRE VIO/WHT WIRE VOLTMETER VSC OFF IND WHT WIRE WHT/BLK WIRE WIPER/WASHER SYSTEM YEL WIRE
