Lexus LX J200 facelift (2012-2015) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Lexus LX J200 facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (101 of 122)

ALT ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLU WIRE CHARGE INDICATOR COMBINATION METER ASSEMBLY IGN+ GENERATOR ASSEMBLY GRN WIRE LEFT COWL SIDE J/B (LEFT END OF DASH) LH-IG FUSE RED WIRE RELAY ENERGIZED RELAY ENERGIZED ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) MET FUSE STARTER ASSEMBLY W/ PTC (LEFT SIDE HEATER OF DASH) WHT WIRE YEL WIRE

Go to component -> Charging circuit -> BLK WIRE

blk wiring diagram (102 of 122)

+B PGND 1 2 3 4 5 6 7 8 9 10 MOR- MOR+ MOL+ MOL- 1 2 3 4 5 6 7 8 CANH CANL COMPUTER DATA LINES SYSTEM 11 25 CAN H CAN L 2 3 4 5 SGND LRDD LRRD IGB 35 36 COMPUTER DATA LINES SYSTEM PCS IND 8 9 13 23 22 10 CAN H CAN L IGB LRRD LRDD SGND BLK WIRE BLU WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISTANCE CONTROL ECU (RIGHT CENTER OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF FUSE ENGINE COMPT) IG B+ LEFT FRONT PRE-COLLISION SEAT BELT MOTOR (BASE OF LEFT "B" PILLAR) LT BLU WIRE MILLIMETER WAVE RADAR SENSOR (CENTER FRONT OF ENGINE COMPT) POWER SUPPLY CIRCUIT PSB FUSE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED LEFT COWL SIDE J/B ECU-IG 1 FUSE (LEFT END OF DASH) RIGHT FRONT PRE-COLLISION SEAT BELT MOTOR (BASE OF RIGHT "B" PILLAR) SEAT BELT CONTROL ECU (LEFT SIDE OF DASH) SKID CONTROL ECU W/ ACTUATOR ASSEMBLY (LEFT REAR OF ENGINE COMPT) VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Pre-collision circuit -> BLK WIRE

blk wiring diagram (103 of 122)

7 8 9 SHIELD AGND ALO ARO ASGN AUXO BLK WIRE BRN WIRE CB+ CGND CV+ GRN WIRE MCI- MCO- MCVD MULTI-MEDIA MODULE RECEIVER ASSEMBLY MUTE NCA WIRE REAR TELEVISION CAMERA (W/O WIDE VIEW FRONT, SIDE MONITOR) (CENTER OF REAR DOOR) RED WIRE SGND SHIELD SHIELD 1 2 3 4 5 6 SHIELD 10 8 7 9 SHIELD 13 14 15 SHIELD 14 12 15 13 SHIELD 2 3 4 SHIELD 22 23 24 25 SHIELD 7 8 9 10 11 12 SHIELD SHIELD SPI+ SPO- STEREO JACK ADAPTER ASSEMBLY 1 UDI- UJSG UPO USB USBG USBV VOR- VOT+ W/ REAR SEAT ENTERTAINMENT SYSTEM W/O REAR SEAT ENTERTAINMENT SYSTEM WHT WIRE

Go to component -> Radio circuit, without mark levinson (3 of 6) -> BLK WIRE

blk wiring diagram (104 of 122)

20 21 22 MIC- 9 10 11 12 13 14 15 16 SHIELD AIR ARON BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE GVI- GVIF HAZARD SWITCH LEFT COWL SIDE J/B (LEFT END OF DASH) LINES SYSTEM COMPUTER DATA MICROPHONE AMPLIFIER MULTI- DISPLAY ASSEMBLY ORG/ WIRE OVERHEAD MODULE (CENTER FRONT OF ROOF) PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER) PASSENGER PASSENGER AIR BAG SEAT BELT ON/OFF WARNING INDICATOR LIGHT PBEW PNK WIRE REAR WINDOW DEFOGGER SWITCH RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT FRONT SPEAKER ASSEMBLY 3 SHIELD SHIELD 1 2 3 4 5 6 SHIELD 13 14 15 SHIELD 17 18 19 20 21 22 23 24 25 SHIELD 22 23 24 25 SHIELD 7 8 9 SHIELD PNK WIRE SUPPLEMENTAL RESTRAINTS SYSTEM TWR+ UIND UPSW VIO WIRE VMTI W/ LEXUS ENFORM W/O LEXUS ENFORM WARNING SYSTEMS WHT WIRE YEL WIRE

Go to component -> Radio circuit, without mark levinson (4 of 6) -> BLK WIRE

blk wiring diagram (105 of 122)

BLK WIRE BLU WIRE CA+ CGND GRN WIRE GRY WIRE INSTRUMENT CLUSTER SYSTEM LEFT STEERING SWITCH LINES SYSTEM COMPUTER DATA MACC MIN MODE SEEK- MULTI-MEDIA MODULE RECEIVER ASSEMBLY OFF HOOK ON HOOK PNK WIRE RED WIRE REV RIGHT STEERING SWITCH SEEK SGND SHIELD SHIELD 10 11 12 13 14 15 16 SHIELD 15 16 SHIELD 17 18 19 20 21 22 23 24 25 SHIELD 9 10 11 SHIELD PNK WIRE SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN) STEERING PAD SWITCH ASSEMBLY SWG SWITCH WIRE SYSTEM INTERIOR LIGHTS UNID UPSW VIO WIRE VMTF VOICE VOL (-) W/ BLUETOOTH HANDS-FREE SYSTEM W/ LEXUS ENFORM W/O LEXUS ENFORM WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without mark levinson (5 of 6) -> BLK WIRE

blk wiring diagram (106 of 122)

1 2 3 4 5 6 7 8 WUO MI+ MI- SLDI MO+ MO- SLDO WUI BKUP LP FUSE BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE CTR + ECU- IG 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FL- FR- RL- RR- FRONT SPEAKER ASSEMBLY 4 FUSE GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED INSTRUMENT CLUSTER SYSTEM LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT FRONT SPEAKER ASSEMBLY 2 LEFT FRONT SPEAKER ASSEMBLY 3 LEFT REAR SPEAKER ASSEMBLY 3 LT GRN WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT COWL SIDE J/B RIGHT FRONT LEFT FRONT SPEAKER SPEAKER ASSEMBLY 1 ASSEMBLY 1 RIGHT REAR SPEAKER ASSEMBLY 3 SHIELD SHIELD 15 16 STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) TMUT GND WFL+ WFR+ TV FUSE (RIGHT END OF DASH) TWL- VIO WIRE WFL- WFR- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without mark levinson (6 of 6) -> BLK WIRE

blk wiring diagram (107 of 122)

10 11 PNK CANH CANL WIRE 15 16 CANN CANP BKUP LP FUSE BLK WIRE BLU WIRE ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES ENGINE STOP ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT) JUNCTION JUNCTION CONNECTOR MAIN BODY ECU COMPUTER (LEFT END DATA LINES OF DASH) SYSTEM P DETECTION SWITCH PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) RED WIRE RELAY ENERGIZED RELAY ENERGIZED LEFT ECU-IG 1 COWL FUSE SIDE J/B (LEFT END OF DASH) SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE) SHIFT LOCK SOLENOID SLS+ STOP LIGHT SWITCH (LEFT SIDE OF DASH) WHT/BLK WIRE

Go to component -> Shift interlock circuit -> BLK WIRE

blk wiring diagram (108 of 122)

120 16 NSW STAR 14 46 STSW STA BATTERY BLK WIRE BLU WIRE BRN WIRE CHARGING CIRCUIT ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ENGINE SWITCH GRN WIRE HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE HOT AT ALL TIMES ST FUSE MAIN BODY ECU (LEFT END OF DASH) PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) RED WIRE RED/BLK WIRE RELAY ENERGIZED IGN FUSE SHORT ST CUT RELAY ST RELAY STARTER ASSEMBLY STR+ STSW WHT WIRE

Go to component -> Starting circuit -> BLK WIRE

blk wiring diagram (109 of 122)

1 2 3 4 5 6 7 GND SGND IGE 19 18 SLR+ SLP 5 6 CANH CANL BLK WIRE BRN WIRE CERTIFICATION ECU (LEFT SIDE OF DASH) LIN COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES ID CODE BOX (LEFT SIDE OF DASH) IGN FUSE JUNCTION LEFT COWL SIDE J/B (LEFT END OF DASH) LIN LT BLU WIRE MAIN BODY ECU (LEFT END OF DASH) RED WIRE RELAY ENERGIZED STEERING LOCK ACTUATOR (ON STEERING COLUMN) STR LOCK FUSE WHT/BLK WIRE

Go to component -> Steering column circuit -> BLK WIRE

blk wiring diagram (110 of 122)

-SR -SL +SR +SL 12 13 14 PNK WIRE AIR ARON BBL+ BBL- BBL+ BCL+ BLK WIRE BLU WIRE BRN WIRE BUCKLE SWITCH CANH RMSW RMIL CANL PAON CENTER AIR BAG SENSOR (CENTER OF DASH) COMPUTER DATA LINES SYSTEM DK DK FIRST STEP SECOND STEP GRN WIRE GRY WIRE LEFT FRONT PRETENSIONER (BASE OF LEFT "B" PILLAR) LEFT FRONT SIDE AIR BAG SQUIB CIRCUIT (UNDER DRIVER'S SEAT) LEFT REAR PRETENSIONER (BASE OF LEFT "C" PILLAR) LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 1 KNEE AIR BAG LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 2 KNEE AIR BAG MULTI- DISPLAY ASSEMBLY P- P+ D+ D- P-AB GSW PK+ PK- PNK WIRE PRETENSIONER RED WIRE SEAT POSITION AIR BAG SENSOR SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN) SR- SRL- SRL+ LSP- LBE- WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE YEL/RED WIRE

Go to component -> Supplemental restraint circuit (1 of 3) -> BLK WIRE

Page 11 of 13

1 2 3 4 5 6 7 8 9 10 11 12 13
