Lexus LX J200 facelift (2012-2015) 1 2 pnk canh canl Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 pnk canh canl, in which he is found in the car Lexus LX J200 facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 1 2 pnk canh canl (1 of 3)
1 2 PNK CANH CANL WIRE
38 37 35 36 MPX- MPX+ CANL CANH
A/C AMPLIFIER (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CAN (+)
COMBINATION METER ASSEMBLY
DISTANCE CONTROL ECU (W/ DYNAMIC RADAR CRUISE CONTROL) (RIGHT CENTER OF DASH)
FOUR WHEEL DRIVE CONTROL ECU (RIGHT END OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES ENGINE ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START ECU- IG 1 FUSE
HOT IN ON OR START IGN FUSE
LEFT COWL SIDE J/B (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
MULTI- DISPLAY ASSEMBLY
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
NETWORK GATEWAY ECU (RIGHT SIDE OF DASH)
PNK WIRE
RED WIRE
RED/BLU WIRE
SEAT BELT CONTROL ECU (LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YAW RATE SENSOR (UNDER CENTER CONSOLE)
YEL WIRE
Go to component -> High/low bus circuit (1 of 2) -> 1 2 PNK CANH CANL WIRE
Wiring diagram 1 2 pnk canh canl (2 of 3)
1 2 3 NE NE- VC
1 2 PNK CANH CANL WIRE
10 11 PNK CANH CANL WIRE
10 18 11 19 SHIELD
12 2 13 1 SHIELD SHIELD
13 1 2 12 SHIELD SGND SCV+ SCB+ SCV-
3 4 2 1 CGND CB+ CV+ CV-
BKUP LP FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CAMERA
CANL CANH 35 36
CLEARANCE SONAR IND
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
IG+ MASTER IND
IG+ ONE STEP DIM
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT ULTRASONIC SENSOR 2
LEFT ULTRASONIC SENSOR 3 (LEFT SIDE OF REAR BUMPER)
LT GRN WIRE
MET FUSE
MULTI-DISPLAY ASSEMBLY (LEFT FRONT OF ENGINE)
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
NE- NE+
PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
PNK WIRE
POWER SUPPLY CIRCUIT
REAR TELEVISION CAMERA (CENTER OF REAR DOOR)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY (RIGHT DOOR MIRROR)
RIGHT ULTRASONIC SENSOR 2 (RIGHT OUTSIDE CORNER OF REAR BUMPER)
RIGHT ULTRASONIC SENSOR 3 (RIGHT SIDE OF REAR BUMPER)
SHIELD
SHIELD 10 7 9 8
SHIELD 11 12 13 14
SHIELD 14 15 13 12
SHIELD 3 4 5 6 7 8 9
SHIELD SHIELD 16 17 15 14
SYSTEM
TELEVISION SIDE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (2 of 2) -> 1 2 PNK CANH CANL WIRE
Wiring diagram 1 2 pnk canh canl (3 of 3)
1 2 PNK CANH CANL WIRE
BLK WIRE
BLK/RED WIRE
BRN WIRE
CA+
CANL CANH 35 36
CB+
CGND
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CV+
ECU- IG 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
IG+ MASTER IND
IG+ ONE STEP DIM
LEFT COWL SIDE J/B (LEFT END OF DASH)
MET FUSE
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
POWER SUPPLY CIRCUIT
REAR TELEVISION CAMERA (CENTER OF REAR DOOR)
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
SHIELD
SHIELD CGND
SHIELD SHIELD
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear view monitoring circuit -> 1 2 PNK CANH CANL WIRE
