Lexus LX J200 facelift 2 (2015-2023) Cruise control circuit, w/o dynamic radar controls

ACCELERATOR PEDAL SENSOR ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CAN (-) CAN (+) CANN CANP CERTIFICATION ECU (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH DIODE (PARK/ NEUTRAL POSITION SWITCH) ECCS EFI- MAIN 1 FUSE EFI- MAIN 1 RELAY ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM LEFT COWL SIDE J/B ASSEMBLY MAIN RELAY ENERGIZED N/ST SW FUSE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) PNK WIRE RED WIRE RELAY ENERGIZED RIGHT END OF DASH) SHIELD SPIRAL CABLE SUB-ASSEMBLY STEERING PAD SWITCH ASSEMBLY STOP FUSE STOP LIGHT SWITCH ASSEMBLY THROTTLE BODY ASSEMBLY (TOP RIGHT FRONT OF ENGINE) TRANSMISSION CONTROL ECU ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE BUZZER CAN INPUT COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CRUISE IND GRN WIRE LEFT COWL SIDE J/B ASSEMBLY LEFT FRONT SPEED SENSOR LEFT REAR SPEED SENSOR LT GRN WIRE MAIN RELAY ENERGIZED METER FUSE ONE STEP DIM ORG/ WIRE POWER SUPPLY CIRCUIT RED WIRE RIGHT FRONT SPEED SENSOR RIGHT REAR SPEED SENSOR SET IND SHIELD SKID CONTROL ECU W/ ACTUATOR ASSEMBLY SUB + TFT VIO WIRE WHT WIRE WHT/BLK WIRE
