Lexus LX J200 facelift 2 (2015-2023) overhead module Wiring diagrams
This page contains all the electrical diagrams for the component. overhead module, in which he is found in the car Lexus LX J200 facelift 2 (2015-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram overhead module (1 of 9)
+SM
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
CAN INPUT
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-IG 2 FUSE
ENGINE ROOM R/B ASSEMBLY
FRONT WASHER SWITCH
FRONT WIPER SWITCH
GRN WIRE
INSTRUMENT CLUSTER SYSTEM
LEFT COWL SIDE J/B ASSEMBLY
LO AUTO
METER FUSE
MIST
MPX
OFF
OFF AUTO
OFF LO AUTO
ORG/ WIRE
OVERHEAD MODULE
POWER SUPPLY CIRCUIT
RAIN SENSOR
RED WIRE
RELAY ENERGIZED
SIG
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY
VIO WIRE
WASHER FLUID RESERVOIR)
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIG
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER ECU (RIGHT END OF DASH)
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
Go to component -> Front wiper/washer circuit -> OVERHEAD MODULE
Wiring diagram overhead module (2 of 9)
A/C AMPLIFIER ASSEMBLY
ACC RELAY
ALL DR LOCK RELAY
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY
CERTIFICATION ECU
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
D DR UNLOCK RELAY
FORWARD RECOGNITION CAMERA
ID CODE BOX
INNER REAR VIEW MIRROR ASSEMBLY
INVERTER RELAY
L/D-DR UNLOCK RELAY
LEFT COWL SIDE J/B ASSEMBLY
LEFT FRONT DOOR LOCK ASSEMBLY
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT VISOR ASSEMBLY
MAIN BODY ECU
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
MULTIPLEX TIL, TELESCOPIC ECU
NETWORK GATEWAY ECU
OVERHEAD MODULE
P/OUTLET RELAY
POWER OUTLET SOCKET ASSEMBLY 1
POWER TILT MOTOR
QUICK HEATER ASSEMBLY
RIGHT END OF DASH)
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT VISOR ASSEMBLY
ROOM LIGHT ASSEMBLY 3
SEAT MEMORY SWITCH
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
STEERING CONTROL ECU
STEERING LOCK ACTUATOR ASSEMBLY
STEERING SENSOR
WHT/BLK WIRE
WINDSHIELD WIPER ECU
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit (2 of 6) -> OVERHEAD MODULE
Wiring diagram overhead module (3 of 9)
AMPLIFIER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GVIF
HOT AT ALL TIMES
LT GRN WIRE
MIC -
MICROPHONE
MO-
MPX-B-2 FUSE
ORG/ WIRE
OVERHEAD MODULE
PARKING ASSIST ECU
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLK WIRE
PPL/WHT WIRE
RED WIRE
REMOTE OPERATION SWITCH
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RSW
SHIELD
TWR+
VIO WIRE
W/ TELEMATICS TRANSCEIVER
W/O TELEMATICS TRANSCEIVER
WHT WIRE
WHT/BLK WIRE
Go to component -> Navigation circuit, 19 speaker (6 of 8) -> OVERHEAD MODULE
Wiring diagram overhead module (4 of 9)
AMPLIFIER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GVIF
HOT AT ALL TIMES
LT GRN WIRE
MIC -
MICROPHONE
MO-
MPX-B-2 FUSE
ORG/ WIRE
OVERHEAD MODULE
PARKING ASSIST ECU
PNK WIRE
PPL/BLK WIRE
PPL/WHT WIRE
RED WIRE
REMOTE OPERATION SWITCH
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RSW
SHIELD
TWR+
VIO WIRE
W/ TELEMATICS TRANSCEIVER
W/O TELEMATICS TRANSCEIVER
WHT WIRE
WHT/BLK WIRE
Go to component -> Navigation circuit, 9 speaker (6 of 8) -> OVERHEAD MODULE
Wiring diagram overhead module (5 of 9)
BACK DOOR CONTROL SWITCH
BLK WIRE
CLOCK ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMBINATION SWITCH ASSEMBLY 2
COOLING BOX ASSEMBLY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FOG FR RELAY ENGINE ROOM R/B ASSEMBLY
FROM J/B- AM 1 FUSE (DIAGRAM 4 OF 9)
GLOVE BOX LIGHT ASSEMBLY
GRN WIRE
HEATER SWITCH ASSEMBLY
INSTRUMENT PANEL REGISTER ASSEMBLY 1
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT COWL SIDE J/B ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REFRESHING SEAT SWITCH
LICENSE PLATE LIGHT ASSEMBLY
LIGHT CONTROL RHEOSTAT
MAIN BODY ECU
MAIN SWITCH ASSEMBLY
MULTI- DISPLAY ASSEMBLY
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
OVERHEAD MODULE
PANEL 1 FUSE
PANEL 2 FUSE
POWER BACK DOOR MAIN SWITCH
PRE-COLLISION SYSTEM CANCEL SWITCH (PRE-CRASH SYSTEM CANCEL SWITCH ASSEMBLY)
REAR HEATER CONTROL PANEL ASSEMBLY
REMOTE OPERATION SWITCH
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SEAT MEMORY SWITCH
SHIFT POSITION INDICATOR
SPIRAL CABLE SUB-ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
TAIL FUSE
TAIL RELAY
TO MOBILE WIRELESS CHARGER CRADLE ASSEMBLY (DIAGRAM 2 OF 9)
TOWING BRAKE CONTROLLER
Go to component -> Power distribution circuit (8 of 9) -> OVERHEAD MODULE
Wiring diagram overhead module (6 of 9)
BLK WIRE
COOLING BOX ASSEMBLY
DOME CUT FUSE
DOME CUT RELAY
DOME FUSE
ECU-IG 2 FUSE
FORWARD RECOGNITION CAMERA
FROM J/B- B 2 FUSE (DIAGRAM 6 OF 9)
GRN WIRE
HEATER SWITCH ASSEMBLY
INNER REAR VIEW MIRROR ASSEMBLY
LEFT COWL SIDE J/B ASSEMBLY
LEFT FOLD SEAT CONTROL ECU
LEFT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
LEFT FRONT TENSION REDUCER
LEFT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
LEFT REFRESHING SEAT SWITCH
LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
MULTIPLEX TILT, TELESCOPIC ECU
NETWORK GATEWAY ECU
OVERHEAD MODULE
REAR HEATER CONTROL PANEL ASSEMBLY
RED WIRE
RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT FRONT FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
RIGHT FRONT TENSION REDUCER
RIGHT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT REAR FOOT LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SUSPENSION CONTROL ECU
TO INVERTER RELAY (DIAGRAM 4 OF 9)
TRANSMISSION CONTROL SWITCH
WINDSHIELD WIPER ECU
Go to component -> Power distribution circuit (9 of 9) -> OVERHEAD MODULE
Wiring diagram overhead module (7 of 9)
AMPLIFIER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GVIF
HOT AT ALL TIMES
LT GRN WIRE
MIC -
MICROPHONE
MO-
MPX-B-2 FUSE
ORG/ WIRE
OVERHEAD MODULE
PARKING ASSIST ECU
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLK WIRE
PPL/WHT WIRE
RED WIRE
REMOTE OPERATION SWITCH
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RSW
SHIELD
TWR+
VIO WIRE
W/ TELEMATICS TRANSCEIVER
W/O TELEMATICS TRANSCEIVER
WHT WIRE
WHT/BLK WIRE
Go to component -> Radio circuit, 19 speaker (6 of 8) -> OVERHEAD MODULE
Wiring diagram overhead module (8 of 9)
AMPLIFIER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
GVIF
HOT AT ALL TIMES
LT GRN WIRE
MIC -
MICROPHONE
MO-
MPX-B-2 FUSE
ORG/ WIRE
OVERHEAD MODULE
PARKING ASSIST ECU
PNK WIRE
PPL/BLK WIRE
PPL/WHT WIRE
RED WIRE
REMOTE OPERATION SWITCH
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RSW
SHIELD
TWR+
VIO WIRE
W/ TELEMATICS TRANSCEIVER
W/O TELEMATICS TRANSCEIVER
WHT WIRE
WHT/BLK WIRE
Go to component -> Radio circuit, 9 speaker (6 of 8) -> OVERHEAD MODULE
Wiring diagram overhead module (9 of 9)
9 SPEAKER 19 SPEAKER
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER)
DCM FUSE
DOOR LOCKS SYSTEM
ECU-ACC 1 FUSE
GPS ANTENNA
GRN WIRE
GRY WIRE
GSW
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT CLUSTER SYSTEM
LEFT COWL SIDE J/B ASSEMBLY
LT BLU WIRE
MCI-
MCO-
MCVD
MIC -
MIN
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
MUTE
NCA WIRE
ORG/ WIRE
OVERHEAD MODULE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/BLK WIRE
PPL/WHT WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RRID
SGND
SHIELD
SIG
SLED
SLPD
SOS SWITCH MICROPHONE AMPLIFIER
SPDP
SPI+
SPO-
STEREO COMPONENT AMPLIFIER ASSEMBLY
SUPPLEMENTAL RESTRAINTS SYSTEM
TELEPHONE ANTENNA CORD SUB-ASSEMBLY
TELEPHONE MAIN ANTENNA
TELEPHONE SUB ANTENNA
TELS
TELSSLD
TMUT
TWR+
USB
USBG
USBS
USBV
VIO WIRE
VOR-
VOT+
WHT WIRE
WHT/BLK WIRE
Go to component -> Telematics circuit -> OVERHEAD MODULE
