Lexus LX J200 facelift 2 (2015-2023) oil pressure sender gauge assembly Wiring diagram
This page shows the only wiring diagram for the component.oil pressure sender gauge assembly, which is found in the car Lexus LX J200 facelift 2 (2015-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pressure sender gauge assembly (1 of 1)
-DP
BACK
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER)
DOWN
ECU-IG 3 FUSE
ENGINE OIL LEVEL SENSOR
ENGINE ROOM R/B ASSEMBLY
ENTER
FUEL SENDER GAUGE ASSEMBLY
GRN WIRE
GVIF
HAZ FUSE
HOT AT ALL TIMES
ILU
LEFT
LEFT COWL SIDE J/B ASSEMBLY
LEFT STEERING PAD SWITCH
LEVEL SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN RELAY ENERGIZED
METER FUSE
METER MIRROR SUB-ASSEMBLY
MPX-B 1 FUSE
MULTI-MEDIA MODULE RECEIVER ASSEMBLY
OIL PRESSURE SENDER GAUGE ASSEMBLY
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT
RIGHT STEERING PAD SWITCH
SPDP
SPIRAL CABLE SUB-ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEREO COMPONENT AMPLIFIER ASSEMBLY
THERMO SWITCH
TOP
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL/GRN WIRE
Go to component -> Instrument cluster circuit (2 of 3) -> OIL PRESSURE SENDER GAUGE ASSEMBLY
