Lexus LX J200 facelift 2 (2015-2023) interior illumination light assembly 1 Wiring diagram
This page shows the only wiring diagram for the component.interior illumination light assembly 1, which is found in the car Lexus LX J200 facelift 2 (2015-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior illumination light assembly 1 (1 of 1)
BLU WIRE
COMPUTER DATA LINES SYSTEM
DOME CUT FUSE
DOME CUT RELAY
DOME FUSE
ECU-ACC 1 FUSE
ECU-IG 7 FUSE
ENGINE ROOM R/B ASSEMBLY
FLCL
FRCL
FSPT
GRN WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INTERIOR ILLUMINATION LIGHT ASSEMBLY 1
INTERIOR ILLUMINATION LIGHT ASSEMBLY 2
LCTY
LCYL
LEFT COWL SIDE J/B ASSEMBLY
LEFT FRONT DOOR COURTESY LIGHT ASSEMBLY
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT ASSEMBLY
MAIN BODY ECU
MPX-B 1 FUSE
ORG/ WIRE
RCTY
RCYL
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR COURTESY LIGHT ASSEMBLY
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (1 of 4) -> INTERIOR ILLUMINATION LIGHT ASSEMBLY 1
