Lexus LX J200 facelift 2 (2015-2023) headlamp cleaner motor, pump assembly Wiring diagram
This page shows the only wiring diagram for the component.headlamp cleaner motor, pump assembly, which is found in the car Lexus LX J200 facelift 2 (2015-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamp cleaner motor, pump assembly (1 of 1)
AUTO
BLU WIRE
COMBINATION SWITCH ASSEMBLY
ECU-ACC 1 FUSE
ECU-IG 7 FUSE
ENG- IG 1 FUSE
ENGINE ROOM R/B ASSEMBLY
GRN WIRE
H-LP CLN FUSE
H-LP CLN RELAY
HEAD
HEADLAMP CLEANER MOTOR, PUMP ASSEMBLY
HEADLIGHT CLEANER SWITCH
HEADLIGHT DIMMER SWITCH ASSEMBLY
HLC
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
LEFT COWL SIDE J/B ASSEMBLY
LEFT HEADLIGHT ECU SUB-ASSEMBLY
LIGHT CONTROL SWITCH
LINL
LT GRN WIRE
MAIN BODY ECU
MPX-B 1 FUSE
OFF
RED WIRE
RELAY ENERGIZED
RIGHT HEADLIGHT ECU SUB-ASSEMBLY
TAIL
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlamp washer circuit -> HEADLAMP CLEANER MOTOR, PUMP ASSEMBLY
