Lexus LX J200 facelift 2 (2015-2023) cls pnk opn Wiring diagram
This page shows the only wiring diagram for the component.cls pnk opn, which is found in the car Lexus LX J200 facelift 2 (2015-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cls pnk opn (1 of 1)
+B IG+
BLK WIRE
BRN WIRE
BUZZER
BZR
CAN INPUT
CLS
CLS PNK OPN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DWN
ECU-IG 2 FUSE
GILL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
KEY LOCK
KEY UNLOCK
LEFT COWL SIDE J/B ASSEMBLY
LEFT COWL SIDE J/B ASSEMBLY (LEFT END OF DASH)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK ASSEMBLY
MAIN BODY ECU
MASTER IND
METER FUSE
OPN
ORG/ WIRE
OVERHEAD MODULE (CENTER FRONT OF ROOF)
PNK WIRE
POWER SUPPLY CIRCUIT
POWER WINDOWS SYSTEM
PPL/BLU WIRE
RED WIRE
RELAY ENERGIZED
S/ROOF FUSE
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SLIDING ROOF CONTROL SWITCH
SUB +
TFT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
Go to component -> Power top/sunroof circuit -> CLS PNK OPN WIRE
