Lexus LX J200 (2007-2012) Heated seats circuit

BLK WIRE BRN WIRE ECU-IG 2 FUSE GRN WIRE HOT IN ON OR START JUNCTION LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT FRONT SEAT HEATER ASSEMBLY LEFT SEAT HEATER SWITCH LH-IG FUSE RIGHT COWL SIDE J/B (RIGHT END OF DASH) RIGHT FRONT SEAT HEATER ASSEMBLY RIGHT SEAT HEATER SWITCH SEAT BACK) SEAT CUSHION) SEAT HEATER CONTROL SEAT HTR FUSE SWL SWR THERMISTOR THL THR+ VGL VGR WHT WIRE WHT/BLK WIRE

A/C CONTROL ASSEMBLY 2 BLK WIRE BLU WIRE COM COMP+ ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES JUNCTION LEFT REAR SEAT HEATER MAIN BODY ECU (LEFT END OF DASH) REAR SEAT HEATER SWITCH RELAY RIGHT REAR SEAT HEATER RLY RR S/HTR FUSE SEAT BACK) SEAT CUSHION) SEAT HEATER CONTROL SWL SWR THERMISTOR THL THR+ WHT WIRE WHT/BLK WIRE
