Lexus LX J200 (2007-2012) right seat heater Wiring diagram
This page shows the only wiring diagram for the component.right seat heater, which is found in the car Lexus LX J200 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right seat heater (1 of 1)
36 35 CANH CANL
A/C CONTROL ASSEMBLY 2 LEFT ILL+ SEAT HEATER
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER ASSEMBLY OUTER MIRROR SWITCH ASSEMBLY
COMB- INATION SWITCH ASSEMBLY
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISP
DISTANCE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START STEERING PAD SWITCH ASSEMBLY MET FUSE
ILLUM- INATION
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT STEERING SWITCH
LIGHT CONTROL RHEOSTAT
MODE
ODO TRIP
OFF HOOK
ON HOOK
ONE STEP DIM
OUTER MIRROR SWITCH ASSEMBLY LEFT FRONT
OVERHEAD ILL MODULE (CENTER FRONT OF ROOF) GILL
PATTERN SELECT SWITCH ASSEMBLY 1
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLU WIRE
RHEOSTAT
RIGHT SEAT HEATER
RIGHT STEERING SWITCH
RSET TC ILL+ TR 27 31 32 33 34 26
SEAT MEMORY SWITCH
SEEK
SHIFT LEVER ILL+ ILLUMINATION (INTERIOR ILLUMINATION ILL- LIGHT ASSEMBLY 1)
SPIRAL CABLE ASSEMBLY (IN STEERING COLUMN)
SWITCH
SWITCH ILL
SWITCH WIRE
TAIL CANCEL
TAIL IND (CANADA)
VIO WIRE
VOICE
VOLUME-
WHT WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> RIGHT SEAT HEATER
