Lexus LX J200 (2007-2012) right rear, right front side air bag sensor assembly shield Wiring diagram
This page shows the only wiring diagram for the component.right rear, right front side air bag sensor assembly shield, which is found in the car Lexus LX J200 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear, right front side air bag sensor assembly shield (1 of 1)
AUTOMATIC FOLDING- UP FUNCTION
AUTOMATIC FOLDING-UP FUNCTION MANUAL FOLDING-UP FUNCTION
BACK DOOR REMOTE CONTROL ASSEMBLY
BLU WIRE
BRN WIRE
DOOR CONTROL RECEIVER
FROM
HEIGHT CONTROL PUMP, MOTOR ASSEMBLY
JUNCTION
LEFT LOWER TAIL GATE LOCK ASSEMBLY
LEFT TIRE BACKUP PRESSURE LIGHT WARNING BULB ECU
POWER BACK DOOR MULTIPLEX UNIT NETWORK ASSEMBLY BODY ECU 2
RIGHT BACKUP LIGHT BULB
RIGHT FOLD RIGHT SEAT FLOOR CONTROL RELEASE ECU MOTOR
RIGHT FRONT POWER SEAT SWITCH ASSEMBLY
RIGHT FRONT SEAT CLIMATE CONTROL ECU
RIGHT FRONT SEAT HEATER ASSEMBLY
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT LOWER TAIL GATE LOCK ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR DOOR ELECTRICAL KEY OSCILLATOR
RIGHT REAR DOOR LOCK ASSEMBLY
RIGHT REAR POWER RIGHT REAR SEAT SEAT SWITCH 1 HEATER
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SEAT CLOSER MOTOR 2 (RIGHT FOLD SEAT LEG LOCK SUB- ASSEMBLY)
RIGHT REAR, RIGHT FRONT SIDE AIR BAG SENSOR ASSEMBLY SHIELD
RIGHT RIGHT FLOOR FLOOR STRIKER STRIKER LIMIT LIMIT SWITCH 2 SWITCH 1
RIGHT RIGHT SEAT SEAT BACK BACK LOCK LOCK SWITCH 1 SWITCH 2
RIGHT SEAT BACK AREA SWITCH
SPIRAL RIGHT CABLE CURTAIN SUB- AIR BAG ASSEMBLY ASSEMBLY SHIELD
W/ CLIMATE CONTROL SEAT
W/O CLIMATE CONTROL SEAT
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 6) -> RIGHT REAR, RIGHT FRONT SIDE AIR BAG SENSOR ASSEMBLY SHIELD
