Lexus LX J200 (2007-2012) right rear header speaker assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right rear header speaker assembly, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear header speaker assembly (1 of 2)
ADPG
AGND
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DISPLAY
GRN WIRE
GRY WIRE
IEEE
INSTRUMENT CLUSTER SYSTEM
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT REAR HEADER SPEAKER ASSEMBLY
LEFT STEERING SWITCH
LINES SYSTEM COMPUTER DATA
MACC
MIN
MODE
NCA WIRE
OFF HOOK
ON HOOK
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
PNK WIRE
RED WIRE
REV
RIGHT FRONT SPEAKER ASSEMBLY 2
RIGHT FRONT SPEAKER ASSEMBLY 3
RIGHT REAR HEADER SPEAKER ASSEMBLY
RIGHT STEERING SWITCH
RLD
RRD
SEEK
SGND
SPIRAL CABLE (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
SWG
SWITCH WIRE
TWR+
VA-
VAL+
VAR+
VIO WIRE
VOICE
VOL (-)
VV-
W/ BLUETOOTH HANDS-FREE SYSTEM
W/ LEXUS ENFORM
W/O LEXUS ENFORM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, with mark levinson (4 of 5) -> RIGHT REAR HEADER SPEAKER ASSEMBLY
