Lexus LX J200 (2007-2012) right front speaker assembly 1 Wiring diagrams

This page contains all the electrical diagrams for the component. right front speaker assembly 1, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

right front speaker assembly 1 wiring diagram (1 of 4)

1 2 3 4 5 6 +B GND 1 2 3 4 5 6 7 8 9 10 11 12 SR+ SL+ 1 2 3 4 5 6 7 8 9 10 RR+ FL+ R-L+ R-R+ RR- FL- FR- FR+ R-L- R-R- AMP 1 FUSE AMP 2 FUSE BKUP LP FUSE BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE CTR- RL- ECU- IG 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FRONT SPEAKER ASSEMBLY 4 FUSE OF DASH) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START INSTRUMENT CLUSTER SYSTEM LEFT COWL SIDE J/B (LEFT END LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT FRONT SPEAKER ASSEMBLY 3 LEFT REAR SPEAKER ASSEMBLY 3 LEFT REAR SPEAKER SET LT GRN WIRE PNK WFL+ WFR- WIRE PNK WIRE PNK WUO MI- SLDO MO- WIRE RED WIRE RIGHT COWL SIDE J/B RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT REAR SPEAKER ASSEMBLY 3 RIGHT REAR SPEAKER SET SPD WUI MI+ SLDI MO+ TMUT STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) TV FUSE (RIGHT END OF DASH) TWL- VIO WIRE W/ BOX SPEAKER ASSEMBLY 1 WFR+ SR- SL- WFL- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, with mark levinson (5 of 5) -> RIGHT FRONT SPEAKER ASSEMBLY 1

right front speaker assembly 1 wiring diagram (2 of 4)

28 29 PNK WIRE ADPG AGND BLK WIRE BLU WIRE BRN WIRE DISPLAY, NAVIGATION MODULE DISPLAY FRONT SPEAKER ASSEMBLY 4 GRN WIRE GRY WIRE INSTRUMENT CLUSTER SYSTEM LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT FRONT SPEAKER ASSEMBLY 3 LEFT REAR SPEAKER ASSEMBLY 3 LINES SYSTEM COMPUTER DATA LT GRN WIRE MACC MCI- MCO- MCVD MIN MUTE NCA WIRE PNK 18 19 WIRE PNK WIRE RED WIRE REV RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT FRONT SPEAKER ASSEMBLY 3 RIGHT REAR SPEAKER ASSEMBLY 3 SGND SPI+ SPO- SWG TWL- TWR+ USB USBG USBV VA- VAL+ VAR+ VIO WIRE VOR- VOT+ VV- W/ LEXUS ENFORM W/ REAR SEAT ENTERTAINMENT SYSTEM W/O LEXUS ENFORM W/O REAR SEAT ENTERTAINMENT SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Navigation circuit, without mark levinson (3 of 4) -> RIGHT FRONT SPEAKER ASSEMBLY 1
